TM-38 < UNIT DISASSEMBLY AND ASSEMBLY > [5MT: RS5F91R] TRANSAXLE ASSEMBLY 26. Remove input shaft front bearing from clutch housing, using suit- able tool. 27. Cut oil channel tube at the base. CAUTION: Do not reuse oil channel. NOTE: Oil channel will be removed with the mainshaft front bearing. 28. Remove mainshaft front bearing and oil channel from clutch housing, using Tool (A). 29. Remove bushings (1) from clutch housing, using suitable tool. 30. Remove differential side oil seals (1) from clutch housing and transaxle case, using suitable tool. CAUTION: Do not damage transaxle case and clutch housing. MCIB0044E Tool number : KV111011S0 ( — ) PCIB1536E PCIB1537E PCIB1534E |
