TM-22 < REMOVAL AND INSTALLATION > [5MT: RS5F91R] POSITION SWITCH POSITION SWITCH Removal and Installation INFOID:0000000009267784 REMOVAL 1. Drain gear oil. Refer to . 2. Disconnect the harness connector (A) from position switch. INSTALLATION 1. Apply recommended sealant to threads of position switch. CAUTION: • Use Genuine Silicone RTV or equivalent. Refer to GI-21, "Recommended Chemical Products and . • Remove old sealant and oil adhering to threads. 2. Install position switch to transaxle case. 4. Refill gear oil. Refer to Inspection INFOID:0000000009267785 INSPECTION AFTER INSTALLATION • Check continuity between position switch terminals. Refer to TM-18, "BACK-UP LAMP SWITCH : Compo- (Back-up lamp switch) and TM-18, "PARK/NEUTRAL POSITION (PNP) SWITCH : Compo- (PNP switch). • Check the oil level and for oil leakage. Refer to JPDIC0733ZZ |
