AV-92 < SYSTEM DESCRIPTION > [DISPLAY AUDIO] SYSTEM NOTE: ® telephone system. ® telephone system allows users who have a Bluetooth ® cellular telephone to make a wireless connection between their cellular telephone and the Bluetooth ® control unit. Hands-free cellular telephone calls can be sent and received. Some Bluetooth ® cellular telephones may not be recognized by the Bluetooth ® control unit. When a cellular telephone or the Bluetooth ® control unit is replaced, the telephone must be paired with the Bluetooth ® control unit. Different cellular telephones may have different pairing procedures, refer to the cellular telephone operating manual. ® telephone system operating instructions. Bluetooth ® Control Unit When the ignition switch is turned to ACC or ON, the Bluetooth ® control unit will power up. During power up, the Bluetooth ® control unit is initialized and performs various self-checks. Initialization may take up to 20 sec- onds. If a phone is present in the vehicle and paired with the Bluetooth ® control unit, Nissan Voice Recognition will then become active. Bluetooth ® telephone functions can be turned off using the Nissan Voice Recognition system. Steering Switches When buttons on the steering switches are pushed, the resistance in steering wheel audio control switch cir- ® control unit uses this signal to perform various functions while navigating through the voice recognition system. The following functions can be performed using the steering switches: ® telephone system • Start a voice recognition session • Answer and end telephone calls • Adjust the volume of calls Microphone The microphone is located in the roof console assembly. The microphone sends a signal to the Bluetooth ® control unit. The microphone can be actively tested during self-diagnosis. Audio Unit The audio unit receives signals from the Bluetooth ® control unit and sends audio signals to the speakers. SPEED SENSITIVE VOLUME SYSTEM Volume level of this system goes up and down automatically in proportion to the vehicle speed. The control level can be selected by the customer. Refer to Owner's Manual for operating instructions. |
