WT-60

< SYMPTOM DIAGNOSIS >

EASY FILL TIRE ALERT DOES NOT ACTIVATE

EASY FILL TIRE ALERT DOES NOT ACTIVATE

Description

INFOID:0000000011280540

The Easy Fill tire alert does not function while inflating a tire when the select lever position is in P-range with

the ignition switch ON.

NOTE:

• After starting to inflate the tire, it takes a few seconds for the easy fill tire alert to function.

• If there is no response for approximately 15 seconds or more after inflating the tires, cancel the use of the

Easy Fill tire alert function or move the vehicle approximately 1 m (3.2 ft.) backward or forward to try again.

The air filler pressure may be weak or out of service area.

• For Easy Fill tire alert, Refer to

WT-11, "Easy Fill Tire Alert Function"

.

Diagnosis Procedure

INFOID:0000000011280541

1.

 LOCATION CHANGE

Move the vehicle to other area and repeat the procedure of the Easy Fill tire alert function. Refer to

WT-11,

"Easy Fill Tire Alert Function"

.

Is the function normal?

YES

>> Inspection End.

NO

>> GO TO 2.

2.

PERFORM BCM SELF-DIAGNOSIS

 With CONSULT

Perform “Self Diagnostic Result” for “AIR PRESSURE MONITOR”.
Is any DTC detected?

YES

>> Perform diagnosis for detected DTC. Refer to

BCS-47, "DTC Index"

.

NO

>> GO TO 3.

3.

CHECK HAZARD WARNING LAMP OPERATION

Check hazard warning lamp operation with hazard switch.
Does the hazard warning lamps operate?

YES

>> GO TO 4.

NO

>> Refer to

EXL-90, "Diagnosis Procedure"

.

4.

PERFORM SELF DIAGNOSTIC RESULT FOR TCM

 With CONSULT

Perform “Self Diagnostic Result” for “TRANSMISSION”.
Is any DTC detected?

YES

>> Perform diagnosis for detected DTC. Refer to

TM-63, "DTC Index"

.

NO

>> GO TO 5.

5.

CHECK HORN OPERATION

Check horn operation.
Is the inspection result normal?

YES

>> GO TO 6.

NO

>> Repair or replace malfunctioning components.

6.

PERFORM SELF DIAGNOSTIC RESULT

 With CONSULT

1. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for

10 minutes.

2. Stop the vehicle.

3. Perform “Self Diagnostic Result” for “AIR PRESSURE MONITOR”.
Is any DTC detected?

YES

>> Perform diagnosis for detected DTC. Refer to

WT-16, "DTC Index"

.

EASY FILL TIRE ALERT DOES NOT ACTIVATE

WT-61

< SYMPTOM DIAGNOSIS >

C

D

F

G

H

I

J

K

L

M

A

B

WT

N

O

P

NO

>> Replace BCM. Refer to

BCS-75, "Removal and Installation"

 (with Intelligent Key system) or

BCS-

135, "Removal and Installation"

 (without Intelligent Key system).

WT-62

< SYMPTOM DIAGNOSIS >

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000011280542

Use the chart below to find the cause of the symptom. If necessary, repair or replace these parts.

×: Applicable

Reference page

WT

-67

WT

-63

WT

-64

WT

-73

FSU-8

—

—

WT

-73

DLN-98

DLN-1

11

FAX-6

, o

r

FSU-5

RA

X

-5

 or

RAX-13

—

—

F

AX-6

 or

FA

X

-4

4

.

BR-6

ST

-5

Possible cause and SUSPECTED PARTS

Imp

rop

er i

nst

al

la

tio

n,

 lo

os

en

es

s

O

ut

-of-ro

un

d

Im

ba

la

nc

e

Incorrect t

ire pressure

Un

ev

en

 tire

 wea

r

De

form

at

ion

 o

r da

ma

ge

No

n-u

nif

orm

ity

Incorrect t

ire size

PROPELLER SHAFT (if

equipped)

DIF

F

ERENTIA

L (i

f equipped)

FRONT AXLE AND

FRONT

SUSP

ENSION

REAR AXLE AND

REAR

SUSP

ENSION

TI

RE

 W

H

EEL

DRIVE

 SHAFT

BRAK

E

ST

EERING

Symptom

TIRE

Noise

×

×

×

×

×

×

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

×

×

×

×

×

×

×

Vibration

×

×

×

×

×

×

×

Shimmy

×

×

×

×

×

×

×

×

×

×

×

×

×

Shudder

×

×

×

×

×

×

×

×

×

×

×

×

Poor quality ride or
handling

×

×

×

×

×

×

×

×

×

×

 WHEEL

Noise

×

×

×

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

×

×

×

×

Shimmy, Shudder

×

×

×

×

×

×

×

×

×

Poor quality ride or
handling

×

×

×

×

×

×

×

WHEEL

WT-63

< PERIODIC MAINTENANCE >

C

D

F

G

H

I

J

K

L

M

A

B

WT

N

O

P

PERIODIC MAINTENANCE

WHEEL

Inspection

INFOID:0000000011280543

WHEEL

1. Check tires for wear and improper inflation.
2. Check wheels for deformation, cracks and other damage. If deformed, remove wheel and check wheel

runout.

3. Remove tire from wheel and mount wheel on a balancer

machine.

CAUTION:

DO NOT use center hole cone-type clamping machines to

hold the wheel during tire removal/installation or balancing

or damage to the wheel paint, cladding or chrome may

result. Use only rim-type or universal lug-type clamping

machines to hold the wheel during servicing.

a. Set dial indicator as shown.
b. Check runout, if runout value exceeds the limit, replace wheel.

Limit
Axial Runout (A)

Refer to

WT-73, "Wheel"

.

Radial Runout (B)

Refer to

WT-73, "Wheel"

.

SEIA0737E
