EM-148
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
UNDERSIZE
Unit: mm (in)
CONNECTING ROD BEARING OIL CLEARANCE
Unit: mm (in)
*: Actual clearance
Grade number
Thickness
Identification color (mark)
0
1.500 - 1.503 (0.0591 - 0.0592)
Black
1
1.503 - 1.506 (0.0592 - 0.0593)
Brown
2
1.506 - 1.509 (0.0593 - 0.0594)
Green
Items
Thickness
Crank pin journal diameter
0.25 (0.0098)
1.626 - 1.634 (0.0640 - 0.0643)
Grind so that bearing clearance is the specified value.
Items
Standard
Limit
Connecting rod bearing oil clearance
0.020 - 0.045 (0.0008 - 0.0018)*
0.070 (0.0028)
