Operation & Maintenance Manual──LG936L Wheel Loader

 76

3.3.4 Braking

z  Never put your foot on the brake pedal unless necessary.

z  Never press the brake pedal again and again unless necessary.

z  Never try to stop the engine and put the high-low speed control lever and the fore-and-aft control

level in the neutral position while driving down sloping ground.



△

!

WARNING



Never use the control lever of the manual brake switch to

brake or slow the speed of the machine while running

unless in an emergency.

3.4 Stopping

3.4.1 Steps to Stop



z  Release the accelerator, and press the brake pedal to

stop the machine. Put the gear control lever in the

neutral position.





z  After safely stopping, push the parking brake switch to lock the machine in place.



z  Level the bucket and other equipment to the ground.



z  Stop the machine on the level ground where there is

no danger of stone falling, coasting or flooding. If it

is necessary to stop the machine on a slope, wedge

the wheels to prevent movement.

z  After stopping, let the cooling water out. The

temperature is below 0℃, if antifreeze is not added. Please refer to

3.5.3 Operation in Cold

Weather

 in this chapter.



3.4.2 Steps to Stop Engine

z  Let the engine run freely for 5 minutes to cool all the parts equally.

Operation & Maintenance Manual──LG936L Wheel Loader

 77

z  Pull the flameout control soft shaft (if assembled).

z  Turn the key to OFF position. And draw it out and keep in a safe place.



△

!

WARNING



Never pull the flameout control soft shaft before the engine

is cooled.



3.4.3 Leaving Machine

z  Use the ladder and handle to climb down facing the machine. Never jump down.

z  Check whether there are particle-likes materials on the engine. If so, clean them immediately to

prevent fire.

z  Clean all the flammable materials around the machine to prevent fire.

z  Lock the door and window, and draw the key.



3.4.4 Do the Followings after Work Everyday

z  Check the fuel reserves.

z  Check the oil level of the engine oil pan and its cleanness. If the oil level is too high or diluted,

find the reasons and solve them.

z  Check the oil pipes, water pipe, gas pipe and other parts for leaking conditions.

z  Check the gearbox, torque converter, steering unit, fixing of front and rear frame, and sealing

conditions. And check whether there are overheating conditions.

z  Check whether the rim bolts, transmission axis bolts and other pins are loose.

z  Add antifreeze if the temperature is below 0℃; drain the water out if there is no antifreeze. Refer

to

3.5.3 Operation in Cold Weather

 in this chapter.

z  Check whether the work equipment is in good working order.

z  Check whether the wheel pressure and outside surface are normal.

z  Add liquid oil to the adding points of work equipment.

z  Check the quantity of the brake oil by opening the oil bowl cover of the brake booster pump.

z  Drain the water in the air tank from the water outlet valve.

z  Clean the outside surface of machine and the inside of the bucket.







Operation & Maintenance Manual──LG936L Wheel Loader

 78



























































Operation & Maintenance Manual──LG936L Wheel Loader

 79

3.5 Operations

3.5.1 Prepare to Work

Clean the working area, and fill-up any hollow spaces. Clear away the sharp stones and roadblocks

that may break the wheels and operation.



3.5.2 Modes of Work

(1)  Loading Operation

z  Work together with a truck which can help improve working efficiency especially for long

distance transportation.

z  When working together, the loader digs the material and the truck transports and unloads the

material:



There are generally two loading and unloading ways:

— Cross Load:

The loader faces the material, then it moves

backward after digging a full load and lets the

auto-unload truck move into the position between

material and the loader. This method costs the

minimum time and can reduce the cycle time most

effectively.



— “V” Shape Load:

The auto-unload truck is fixed and forms almost a

60°angle with the backward direction of the loader.

After digging, the loader moves backward and turns

the designated degree and moves forward to the

truck.

The smaller the loader work angle is, the more

efficient the work is.
