SUPER ALL WHEEL CONTROL (S-AWC)

TSB Revision

CIRCUIT DIAGRAMS

90-353

NOTES

CRUISE CONTROL SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-354

CRUISE CONTROL SYSTEM

M1901032901650

36

FUSIBLE
LINK

RELAY BOX

ENGINE
COMPARTMENT

MFI
RELAY

THROTTLE
ACTUATOR
CONTROL
MOTOR
RELAY

ENGINE
CONTROL
MODULE

BATTERY
BACKUP

THROTTLE VALVE
DRIVE POWER
SUPPLY

POWER
SUPPLY

MFI SYSTEM

CRUISE CONTROL SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-355

34

FUSIBLE
LINK

POWER
DISTRIBUTION
SYSTEM

IGNITION
SWITCH (IG1)

ETACS-
ECU

IG1
RELAY

STOPLIGHT
SWITCH

·SHIFT LOCK MECHANISM
·SPARE CONNECTOR
 (FOR TRAILER LIGHTS)
·STOPLIGHT

STOPLIGHT RELAY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CRUISE CONTROL SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-356

CRUISE CONTROL SYSTEM (CONTINUED)

HALL IC

ENGINE
CONTROL
MODULE

ACCELERATOR
PEDAL POSITION
SENSOR

THROTTLE
ACTUATOR
CONTROL
MOTOR

THROTTLE
BODY
ASSEMBLY

HALL IC

(SUB)

HALL IC

(MAIN)

HALL IC

(SUB)

(MAIN)

<2.4L ENGINE>
