Mitsubishi Outlander GS45X. Manual - part 317

SUPER ALL WHEEL CONTROL (S-AWC)

TSB Revision

CIRCUIT DIAGRAMS

90-349

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ASC-ECU

TRANSAXLE
CONTROL
MODULE

G AND YAW RATE SENSOR

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

INPUT SIGNAL

·COLUMN SWITCH
 (LIGHTING SWITCH)
·LIGHTING
 CONTROL SENSOR
 <VEHICLES WITH
 AUTOMATIC LIGHT>

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE
Y : YELLOW     SB : SKY BLUE     BR :BROWN     O : ORANGE     GR : GRAY
R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SUPER ALL WHEEL CONTROL (S-AWC)

TSB Revision

CIRCUIT DIAGRAMS

90-350

SUPER ALL WHEEL CONTROL (S-AWC) (CONTINUED)

ETACS-
ECU

COMBINATION
METER

FUSIBLE
LINK

36

AWC SWITCH

A/C
CONTROL
PANEL

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

CPU

·AUDIO SYSTEM
·HANDS-FREE
 INTERFACE SYSTEM
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·UNIVERSAL SERIAL BUS
 (USB) BOX

·AUDIO SYSTEM
·HANDS-FREE
 INTERFACE SYSTEM
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·UNIVERSAL SERIAL BUS
 (USB) BOX

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

RHEOSTAT

·ANTI-LOCK
 BRAKING SYSTEM
 (ABS) AND ACTIVE
 STABILITY CONTROL
 SYSTEM (ASC)
·HEADLIGHT MANUAL
 LEVELING SYSTEM
·INVECS-II 6A/T

THEFT-ALARM
SYSTEM

RELAY BOX

ENGINE
COMPARTMENT

SUPER ALL WHEEL CONTROL (S-AWC)

TSB Revision

CIRCUIT DIAGRAMS

90-351

CPU

ETACS-ECU

CAN TRANSCEIVER
CIRCUIT

LCD

·TARMAC
·SNOW
·LOCK

·ANTI-LOCK
 BRAKING SYSTEM
 (ABS) AND ACTIVE
 STABILITY CONTROL
 SYSTEM (ASC)
·AUDIO SYSTEM
·CRUISE
 CONTROL SYSTEM
·HANDS-FREE
 INTERFACE SYSTEM
·HEADLIGHT MANUAL
 LEVELING SYSTEM
·INVECS-II 6A/T
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REAR SEAT
 ENTERTAINMENT SYSTEM
·SPARE CONNECTOR
 (FOR REAR DISPLAY)
·UNIVERSAL SERIAL BUS
 (USB) BOX

ETACS-ECU

(FUSE     )

12

JOINT
CONNECTOR
(CAN1)

(CAN DRIVE CIRCUIT)

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL
 SYSTEM (ASC)
·CENTRAL DOOR LOCKING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER TONE
 ALARM <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·KEYLESS OPERATING SYSTEM
 (KOS)
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
 SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

NOTE

:

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SUPER ALL WHEEL CONTROL (S-AWC)

TSB Revision

CIRCUIT DIAGRAMS

90-352

SUPER ALL WHEEL CONTROL (S-AWC) (CONTINUED)

ETACS-
ECU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

FRONT SIDE

DATA LINK
CONNECTOR

ETACS-ECU

(FUSE     )

5

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER
