VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-23

CODE CHART

NOTE: *: Check digit means a single number, or letter X, used

to verify the accuracy of transcription of vehicle identification

number.

No. Item

Content

1

Country

J

Japan

2

Make

A Mitsubishi Motors Corporation.

3

Vehicle type

4

Multi-purpose vehicle

4

Others

Gross Vehicle Weight Rating/Passenger

car Restraint System

A 4001-5000 lbs/Curtain Airbags (1st

and 2nd Seat) and Seat-Mounted

Side Airbags <VEHICLES FOR

USA AND CANADA>

J

5001-6000 lbs/Curtain Airbags (1st

and 2nd Seat) and Seat-Mounted

Side Airbags <VEHICLES FOR

USA AND CANADA>

L

4001-5000 lbs/Curtain Airbags (1st

and 2nd Seat) and Seat-Mounted

Side Airbags <VEHICLES FOR

MEXICO>

M 5001-6000 lbs/Curtain Airbags (1st

and 2nd Seat) and Seat-Mounted

Side Airbags <VEHICLES FOR

MEXICO>

5

Line

S OUTLANDER (FWD)

T

OUTLANDER (AWD)

6

Price class

2

Low

3

Medium

4

High

5

Premium

7

Body

A 5-door wagon <VEHICLES FOR

USA AND CANADA>

1

5-door wagon <VEHICLES FOR

MEXICO>

8

Engine

W 2.4 L (4B12) MIVEC

X 3.0 L (6B31) MIVEC

9

Check digits*

0, 1, 2, 3, -----------9, X

10

Model year

B 2011 year

11

Plant

U Mizushima

Z

Okazaki

12

Serial number 000001 to 999999

1 2 3 4 5 6 7 8 9 10 11

12

J A 4 M S 3 1 X 1 8 Z 0 0 0 0 0 1

AC710099

9

AD

B

A

J

\

VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-24

VEHICLE IDENTIFICATION CODE PLATE

M1001005400376

The vehicle information code plate is riveted to the face of the
passenger’s door sill.
CODE CHART

For monotone color vehicles, the body color code shall be indi-
cated.

TIRE AND LOADING INFORMATION PLACARD

M1001015800159

The tire and loading information placard is located on the inside
sill of the driver’s door.

No. Item

Example

Content

1

MODEL

CW6WX
LSYZL2M

CW6WX: Vehicle model

LSYZL2M: Model series

2

ENGINE

6B31

Engine model

3

EXT

G44B

Exterior code

4

TRANS
AXLE

W6AJA
2352

W6AJA:Transmission model
2352: Rear differential final
gear ratio (a decimal point is
omitted)

5

COLOR

G44

Body color code

6

INT

11E

Interior code

7

OPT

Z06

Equipment code

1

2

3

4

5

6

7

AC704143

AC704140AB

VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-25

THEFT PROTECTION LABEL

M1001015700970

CAUTION

When replacing a part that has the theft protection plate,
label or stamp on it, be sure that the part has either A or B
shown in the figure. It is illegal if both A and B are
attached, or neither A nor B is attached.
In order to protect against theft, a Vehicle Identification Number
(VIN) is attached as a plate or label to the following major parts
of the engine and transaxle, as well as main outer panels:
Engine cylinder block, Transaxle housing, Front end upper bar
and Front floor crossmember front.
In addition, a theft-protection label is attached to replacement
parts for the body outer panel main components, and the same
data is stamped into replacement parts for the engine and the
transaxle.

CAUTION

Cautions regarding panel repairs:

• When repainting original parts, do so after first masking

the theft-protection label. After painting, be sure to peel
off the masking tape.

• The theft-protection label for replacement parts is cov-

ered by masking tape, so such parts can be painted as
is. The masking tape should be removed after painting
is finished.

• The theft-protection label should not be removed from

original parts or replacement parts.

.

AC704152

Theft protection plate and label

A: For original parts

B: For replacement parts

AC

VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-26

LOCATIONS

Label area (A:Original equipment parts)

AC710022

AC

1

2

AC710023

Front end upper bar (engine room)

AD

A

1

AC710024

Front floor crossmember front

AD

A

2
