DIAGNOSIS TSB Revision CONTROLLER AREA NETWORK (CAN) 54C-567 STEP 28. Check the CAN bus lines between intermediate connector A-02. CAUTION A digital multimeter should be used. For details refer to CAUTION The test wiring harness should be used. For details refer to (1) Disconnect intermediate connector C-29 and ABS-ECU connector A-02, and measure the resistance between the (2) Turn the ignition switch to the "LOCK" (OFF) position. CAUTION Disconnect the negative battery terminal. For details refer . (3) Disconnect the negative battery terminal. AC305206 CONNECTOR: A-02 AG A-02 (GR) HARNESS SIDE AC305231AI CONNECTOR: C-29 |
