Mitsubishi Lancer Evolution 8. Manual - part 175





MPI – TROUBLESHOOTING

13A-86

Remarks
*1. The duration that injectors operate represents the time during which the power supply voltage is 11V, and cranking speed

is 250rpm or less.

*2. When the vehicle is new (500km or less on the clock), the injector operating time may be as much as 10% longer than the

standard time.

*3. When the vehicle is new (500km or less on the clock), the stepper motor step may be as much as 30 steps more than the

standard value.

This is not shown when check motor service data is selected.

Item
No.

Check
Items

Checking Conditions

Normal
condition

Code No. or
Checking
Procedure
No.

Page

Rapid
deceleration
from 4,000rpm

200mV or less

Engine: after warming up
((lean by decelerating,
rich by racing)

During harsh
racing

600 to 1,000mV

Idle running

A1

O

2

 sensor

Engine: after warming up
(as well as using the O

2

sensor signal to check
air/fuel ratio), control
status is checked by
engine ECU

2,500rpm

400mV or less
600

↔

1,000m

V (changes)

Code
No.P0130

13A-16

24

 ★

Vehicle
speed
sensor

Driving at 40km/h

Approx. 40km/h

Code
No.P0500

13A-30

81

 ★

Learned
value

Engine: warmed up, no load 2,500rpm
(during fuel/ratio feedback control)

-12.5 to 12.5%

Code
No.P0170

13A-19

82

 ★

Feedback

Engine: warmed up, no load 2,500rpm
(during fuel/ratio feedback control)

-20 to 20%

Code
No.P0170

13A-19

Idle running

15 to 35%

-

-

87

 ★

Engine
load

Engine: after warming up

2,500rpm

15 to 35%

-

-

Foot off the
throttle pedal

8 to 16%

Foot
depressing
throttle pedal

Increases in
response to
pedal pressure

8A

 ★

TPS1
(Throttle
valve
opening)



Engine: after

warming up



Ignition switch: ON

(engine stopped)

Throttle pedal
fully open

80 to100%

Code
No.P0120

13A-13

MPI – TROUBLESHOOTING

13A-87

7. ACTUATOR TEST TABLE

Item
No.

Check
Items

Drive details

Checking Conditions

Normal
condition

Code No. or
Checking
Procedure
No.

Page

01

No.1
injector

Cuts fuel to No.1
injector

Code
No.P0201

13A-20

02

No.2
injector

Cuts fuel to No.2
injector

Code
No.P0202

13A-21

03

No.3
injector

Cuts fuel to No.3
injector

Code
No.P0203

13A-22

04

No.4
injector

Cuts fuel to No.4
injector

Engine: after warming up, engine
idling
(Fuel supply to each injector is
cut in turn. Cylinders where the
idling condition does not change
are checked)

Idling
condition
changes
(either
fluctuating,
or stalling
engine)

Code
No.P0204

13A-23

Pinch the
return hose
with fingers,
and feel for
the pulse of
fuel flowing

Pulse is
felt

07

Fuel
pump

Fuel pump which
circulates fuel
operates



Engine:

cranking



Fuel pump:

forced driving

Checks to be
done for both the
above conditions

Listen for the
sound of the
pump near
the fuel tank

Operating
noise is
audible

Procedure
No.23

13A-63

08

Purge
control
solenoid
valve

Solenoid valve
turns from OFF
to ON

Ignition switch: ON

Operating
noise is
audible
when
driven

Procedure
No.30

13A-75

09

Fuel
pressure
control
solenoid
valve

Solenoid valve
turns from OFF
to ON

Ignition switch: ON

Operating
noise is
audible
when
driven

Procedure
No.31

13A-76

12

Waste
gate
solenoid
valve

Solenoid valve
turns from OFF
to ON

Ignition switch: ON

Operating
noise is
audible
when drive

Procedure
No.33

13A-78

13

Fuel
pump
relay - 3

Fuel pump relay
–3 turns from
OFF to ON



Ignition switch: ON



Listen for sound of pump

operating near the fuel tank

Operating
noise is
audible
when
driven

Procedure
No.23

13A-63

17

Standard
ignition
timing

Sets engine ECU
to ignition timing
adjustment mode



Engine: idling



Timing light is set

5ºBTDC

-

-

21

Fan
controller

Radiator fan
motor is driven

Ignition switch: ON

Fan motor
rotates at
high
speed

Procedure
No.24

13A-65

36

Secondary
air control
solenoid
valve

Solenoid valve
turns from OFF
to ON

Ignition switch: ON

Operating
noise is
audible
when
driven

Procedure
No.32

13A-77

37

Condenser
fan (HI)

Condenser fan
motor is driven



Ignition switch: ON

Fan motor
rotates at
high
speed

38

Condenser
fan (LOW)

Condenser fan
motor is driven



Ignition switch: ON

Fan motor
rotates at
low speed

Procedure
No.25

13A-67

MPI – TROUBLESHOOTING

13A-88

8. ENGINE ECU CHECKS
8-1 Terminal voltage chart

Engine ECU connectors

Item
No.

Check Items

Checking Conditions (engine condition)

Normal condition

1

No.1 injector

9

No.2 injector

24

No.3 injector

2

No.4 injector

Engine: after warming up, from engine idling
the throttle pedal is suddenly depressed
(Fuel supply to each injector is cut in turn.
Cylinders where the idling condition does not
change are checked)

Momentary slight drop from 11 to 14V

Engine: idling

1V or less

3

O

2

 sensor

Engine: 5,000 rpm

Battery voltage

5

Secondary air
control solenoid
valve

Ignition switch: ON

Battery voltage

8

Alternator G
terminal



Engine: after warming up, idling



Radiator fan: not operating



Headlights: OFF

 ON



Brake light: OFF

→

ON



Rear demister switch: OFF

→

 ON

Voltage increase 0.2 to 3.5V

11

Ignition coil
No.1 – No.4

12

Ignition coil
No.2 – No.3

Engine: 3,000rpm

0.3 to 3.0V

14

Stepper motor
coil (A1)

28

Stepper motor
coil (A2)

15

Stepper motor
coil (B1)

29

Stepper motor
coil (B2)

Engine: Immediately after warm engine has
finished starting up

Battery voltage

↔

0 to 6V (repeatedly changing)

Ignition switch: ON

Battery voltage

16

Purge control
solenoid valve

Engine: idling

1V or less

Radiator fan not operating

0 to 0.3V

18

Fan controller

Radiator fan operating

0.7V or more

Engine: idling

0 to 1V

19

Air flow sensor
reset signal

Engine: 3,000rpm

6 to 9V

20A/C relay



Engine: idling



A/C switch: OFF

 ON (compressor

operating)

Battery voltage or transient 6V or more

 1V or

less

Ignition switch: ON

Battery voltage

21

Fuel pump
relay

Engine: idling

1V or less

22

Engine warning
light

Engine switch: LOCK (OFF)

 ON

1V or less

 Battery voltage (after several

seconds)

Fan not operating (cooling water temp.: 90ºC
or less)

Battery voltage

30Compressor

fan motor relay
(HI)

Fan high speed operation (cooling water
temp.: 105ºC or more)

1V or less

26038AU

MPI – TROUBLESHOOTING

13A-89

Item
No.

Check Items

Checking Conditions (engine condition)

Normal condition

Fan not operating (cooling water temp. 90ºC)
or less)

Battery voltage

31

Condenser fan
motor relay
(LOW)

Fan low speed operation (cooling water temp.
95ºC to 100ºC or more)

1V or less

Ignition switch: ON

Battery voltage

35

Intercooler
spray relay

Ignition switch: LOCK (OFF)

1V or less

Battery voltage

41

Waste gate
solenoid valve

Ignition switch: ON
Engine: after warming up, idling (using
Premium petrol)

1V or less

42

Voltage applied
to sensor

Ignition switch: ON

4.9 to 5.1V

Engine: cranking

0.4 to 4.0V

43

Crank angle
sensor

Engine: idling

1.5 to 2.5V

When water temp.:-20ºC

3.9 to 4.5V

When water temp.: -0ºC

3.2 to 3.8V

When water temp.:20ºC

2.3 to 2.9V

When water temp.:40ºC

1.3 to 1.9V

When water temp.:60ºC

0.7 to 1.3V

44

Water temp.
sensor

Ignition
switch:ON

When water temp.:80ºC

0.3V to 0.9V

45

Tachometer
output

Engine speed: 3,000rpm

0.3 to 3.0V

47
59

Power supply

Ignition switch: ON

Battery voltage

Ignition switch: ON

Battery voltage

48

Fuel pressure
control solenoid
valve

Engine: Cranking

 idling  (within about 2

minutes)

1V or less

 Battery voltage

Engine: cranking

0.4 to 3.0V

50Cam position

sensor

Engine: idling

0.5 to 2.0V

At altitude 0m

3.8 to 4.2V

At altitude 600m

3.5 to 3.9V

At altitude 1,200m

3.3 to 3.7V

51

Atmospheric air
pressure
sensor

Ignition switch: ON

At altitude 1,800m

3.0 to 3.4V

52

Alternator FR
terminal



Engine: after warming up, idling



Radiator fan: not operating



Headlights: OFF

 ON



Brake lights:  OFF

 ON



Rear demister switch OFF

 ON

Voltage drops

54

Power steering
fluid pressure
switch

Engine: after
warming up, idling

Steering wheel: still
condition

Battery voltage

55

Fuel pump
relay –3

Engine: From idling condition, throttle pedal is
depressed suddenly

From 1V or less, there is a slight momentary
increase

Ignition switch: LOCK (OFF)

Battery voltage

57

Engine control
relay

Ignition switch: ON

1V or less

60Back-up power

supply

Ignition switch: LOCK (OFF)

Battery voltages

Engine: idling

61

Air flow sensor

Engine: 2,500rpm

2.2 to 3.2V

When intake air
temp.:-20ºC

3.8 to 4.4V

When intake air
temp.: -0ºC

3.2 to 3.8V

When intake air
temp.:20ºC

2.3 to 2.9V

When intake air
temp.:40ºC

1.5 to 2.1V

When intake air
temp.:60ºC

0.8 to 1.4V

62

Intake air temp.
sensor

Ignition switch: ON

When intake air
temp.:80ºC

0.4 to 1.0V
