TRANSAXLE

TSB Revision

AUTOMATIC TRANSAXLE OVERHAUL

23B-35

18.Turn the transaxle over so that the installation surface of the

torque converter housing is facing up.
Install special tool MD998913 in a dial gauge, and then
move special tool MB991631 <F4A42> or MB991632
<F4A51> and measure its movement.

Standard value of end play (Reference):

1.65

− 2.11 mm (0.065 − 0.083 inch)

19.Select a pressure plate whose thickness corresponds to the

measured amount of movement from the table below.
NOTE: This illustration shows F4A51.

PRESSURE PLATE FOR LOW-REVERSE BRAKE < F4A42>

PRESSURE PLATE FOR OW-REVERSE BRAKE <F4A51>

MOVEMENT
AMOUNT
mm (in)

THICKNESS
mm (in)

ID
SYMBOL

PRESSURE
PLATE
PART NO.

1.3

− 1.5

(0.051

− 0.059)

1.6 (0.063)

L

MD759567

1.5

− 1.7

(0.059

− 0.067)

1.8 (0.071)

1

MD759414

1.7

− 1.9

(0.067

− 0.075)

2.0 (0.079)

0

MD759415

1.9

− 2.1

(0.075

− 0.083)

2.2 (0.087)

2

MD759416

2.1

− 2.3

(0.083

− 0.091)

2.4 (0.094)

4

MD759417

2.3

− 2.5

(0.091

− 0.098)

2.6 (0.102)

6

MD759418

2.5

− 2.7

(0.098

− 0.106)

2.8 (0.110)

8

MD759419

2.7

− 2.9

(0.106

− 0.114)

3.0 (0.118)

D

MD759420

MOVEMENT
AMOUNT
mm (in)

THICKNESS
mm (in)

ID
SYMBOL

PRESSURE
PLATE
PART NO.

1.0

− 1.2

(0.039

− 0.047)

1.6 (0.063)

F

MD759568

1.2

− 1.4

(0.047

− 0.055)

1.8 (0.071)

E

MD759425

1.4

− 1.6

(0.055

− 0.063)

2.0 (0.079)

D

MD759426

1.6

− 1.8

(0.063

− 0.071)

2.2 (0.087)

C

MD759427

AKX01069AB

MD998913

MB991631
<F4A42> OR
MB991632
<F4A51>

AKX01123

<F4A42>

MD998913

MB991631

AB

MOVEMENT
AMOUNT

AKX01124

<F4A51>

MD998913

MB991632

AB

MOVEMENT
AMOUNT

TRANSAXLE

TSB Revision

AUTOMATIC TRANSAXLE OVERHAUL

23B-36

CAUTION

If necessary, take the measurements in steps 9 to 18 after
replacing the pressure plate, brake plate and brake disc.
20.Remove all parts and special tools that were installed to

take the measurements in steps 9 to 18. Remove and
separate the pressure plate and snap ring chosen in steps
12, 16 and 18.

21.Install the snap ring into the groove of transaxle case output

shaft bore.

22.Use special tools MB990930 and MB990938 to tap the

output shaft bearing outer race in the transaxle case.

CAUTION

Do not reuse the bolt, as it has had sealant applied.
23.Tighten the mounting bolts of the output shaft bearing

retainer to the specified torque.

Tightening torque:

23

± 3 N⋅m (17 ± 2 ft-lb) <F4A42>

54

± 5 N⋅m (40 ± 4 ft-lb) <F4A51>

1.8

− 2.0

(0.071

− 0.079)

2.4 (0.094)

B

MD759428

2.0

− 2.2

(0.079

− 0.087)

2.6 (0.102)

A

MD759429

2.2

− 2.4

(0.087

− 0.094)

2.8 (0.110)

0

MD759430

2.4

− 2.6

(0.094

− 0.102)

3.0 (0.118)

1

MD759431

MOVEMENT
AMOUNT
mm (in)

THICKNESS
mm (in)

ID
SYMBOL

PRESSURE
PLATE
PART NO.

AKX01060

MB990938

MB990930

AB

AKX01038

TRANSAXLE

TSB Revision

AUTOMATIC TRANSAXLE OVERHAUL

23B-37

24.Use special tool MD998350 to install the collar and taper

roller bearing on the output shaft.

25.Apply ATF to a new jam nut, and use special tools

MB990607 and MB991625 to tighten the jam nut to the
specified torque. Then turn back one turn, and tighten to the
specified torque again.

Tightening torque: 167

± 10 N⋅m (123 ± 7 ft-lb)

NOTE: The jam nut is reverse threaded.

26.Move the output shaft to measure the end play and record

the measurement value.

27.Remove the parts that were installed in steps 22 to 25.
28.Select a spacer whose thickness corresponds to the

measured amount of movement from the following table.

SPACER FOR OUTPUT SHAFT

AKX01061

MD998350

AB

AKX01062

MB991625

MB990607

AB

MOVEMENT
AMOUNT
mm (in)

THICKNESS
mm (in)

ID
SYMBOL

PRESSURE
PLATE
PART NO.

1.81

− 1.85

(0.0713

− 0.0728)

1.88 (0.0740) 88

MD756579

1.85

− 1.89

(0.0728

− 0.0744)

1.92 (0.0756) 92

MD756580

1.89

− 1.93

(0.0744

− 0.0760)

1.96 (0.0772) 96

MD756581

1.93

− 1.97

(0.0760

− 0.0776)

2.00 (0.0787) 00

MD756582

1.97

− 2.01

(0.0776

− 0.0791)

2.04 (0.0803) 04

MD756583

2.01

− 2.05

(0.0791

− 0.0807)

2.08 (0.0819) 08

MD756584

2.05

− 2.09

(0.0807

− 0.0823)

2.12 (0.0835) 12

MD756585

2.09

− 2.13

(0.0823

− 0.0839)

2.16 (0.0850) 16

MD756586

2.13

− 2.17

(0.0839

− 0.0854)

2.20 (0.0866) 20

MD756587

AKX01063

TRANSAXLE

TSB Revision

AUTOMATIC TRANSAXLE OVERHAUL

23B-38

29.Repeat steps 22 to 25 again, installing each part and using

the appropriate adjustment spacer determined in step 28.

30.Stake the jam nut with a punch (two places).

2.17

− 2.21

(0.0854

− 0.0870)

2.24 (0.0882) 24

MD756588

2.21

− 2.25

(0.0870

− 0.0886)

2.28 (0.0898) 28

MD756589

2.25

− 2.29

(0.0886

− 0.0902)

2.32 (0.0913) 32

MD756590

2.29

− 2.33

(0.0902

− 0.0917)

2.36 (0.0929) 36

MD756591

2.33

− 2.37

(0.0917

− 0.0933)

2.40 (0.0945) 40

MD756592

2.37

− 2.41

(0.0933

− 0.0949)

2.44 (0.0961) 44

MD756593

2.41

− 2.45

(0.0949

− 0.0965)

2.48 (0.0976) 48

MD756594

2.45

− 2.49

(0.0965

− 0.0980)

2.52 (0.0992) 52

MD756595

2.49

− 2.53

(0.0980

− 0.0996)

2.56 (0.1008) 56

MD756596

2.53

− 2.57

(0.0996

− 0.1012)

2.60 (0.1024) 60

MD756597

2.57

− 2.61

(0.1012

− 0.1028)

2.64 (0.1039) 64

MD756598

2.61

− 2.65

(0.1028

− 0.1043)

2.68 (0.1055) 68

MD756599

2.65

− 2.69

(0.1043

− 0.1059)

2.72 (0.1071) 72

MD760685

2.69

− 2.73

(0.1059

− 0.1075)

2.76 (0.1087) 76

MD760686

MOVEMENT
AMOUNT
mm (in)

THICKNESS
mm (in)

ID
SYMBOL

PRESSURE
PLATE
PART NO.

AKX01064
