TROUBLESHOOTING DIESEL FUEL 13A-364 STEP 9. Connector check: C-103 engine-ECU Q: Is the check result normal? YES : Check and repair harness between C-115 (terminal No. 4) accelerator pedal position • Check power supply line for damage. NO : Repair or replace the connector. STEP 10. Perform voltage measurement at C-103 • Measure engine-ECU terminal voltage. • Ignition switch: ON • Voltage between terminal No. 150 and earth. OK: 0.7 − 1.3 V Q: Is the check result normal? YES : Go to Step 12 . NO : Go to Step 11 . AKA00090 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 146 147 148 149 150 151 152 153 154 155 156 157 158 117 145 116 144 C-103 (B) C-103 (B) <R.H. drive vehicles> Harness side connector <L.H. drive vehicles> Connector: C-103 AB AK700804 1 6 5 4 3 2 C-115 (B) C-115 (B) Connector: C-115 <R.H. drive vehicles> <L.H. drive vehicles> AB Harness side connector AKA00090 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 146 147 148 149 150 151 152 153 154 155 156 157 158 117 145 116 144 C-103 (B) C-103 (B) <R.H. drive vehicles> Harness side connector <L.H. drive vehicles> Connector: C-103 AB |
