Mazda 6. Manual - part 398

ST–8

SPECIAL TOOLS

SUSPENSION

A6E941001013W01

End Of Sie

BODY

A6E941001047W01

End Of Sie

49 T034 1A0

Coil spring
compressor set

49 T034 101

Coil spring
compressor

49 T034 105

Attachment

49 0107 680A

Engine stand

49 T028 3A0

Ball joint puller
set

49 T034 202A

Guide

49 B034 216

Installer

49 S120 620

Bearing installer

49 T034 203

Attachment

49 G030 797

Handle

49 U034 204

Dust boot
installer

49 U027 005

Bearing installer

49 G026 103

Support block

49 E017 5A0

Engine support
set

49 G033 102

Handle

49 G033 106

Attachment

49 W034 308

Puller and
installer

49 8038 785A

Dust boot
installer

49 0305 870A

Window tool set

49 G050 1A0

Sealant
remover

—

SPECIAL TOOLS

ST–9

BODY ELECTRICAL SYSTEM

A6E941001047W02

End Of Sie

HEATER AND AIR CONDITIONER SYSTEMS

A6E941001038W01

End Of Sie

49 H066 002

Deployment tool

49 D066 002
Adapter
harness

49 G066 003
Adapter
harness

49 L066 002
Adapter
harness

49 N088 0A0
Fuel and
Thermometer
checker

WDS

49 C061 0A0B

Gas Charge Set

49 C061 012

Anti-Back Flow
Valve

49 C061 013

Gas Leak
Tester

49 G061 001

Spring lock
coupling
disconnect tool

—

—

CONTENTS

Mazda6
Bodyshop
Manual

FOREWORD

This bodyshop manual is intended for

use by technicians of Authorized Mazda
Dealers to help them service and repair
Mazda vehicles. It can also be useful to
owners and operators of Mazda vehicles in
performing limited repair and maintenance
on Mazda vehicles.

For proper repair and maintenance, a

thorough familiarization with this manual is
important, and it should always be kept in a
handy place for quick and easy reference.

All the contents of this manual, including

drawings and specifications, are the latest
available at the time of printing.
As modifications affecting repair or
miantenance occur, relevant information
supplementary to this volume will be made
available at Mazda dealers. This manual
should be kept up-to-date.

Mazda Motor Corporation reserves the

right to alter the specifications and contents
of this manual without obligation or
advance notice.

All rights reserved. No part of this book

may be reproduced or used in any form or
by any means, electronic or mechanical
including photocopying and recording and
the use of any kind of information storage
and retrieval system-without permission in
writing.

Mazda Motor Corporation

HIROSHIMA, JAPAN

APPLICATION:

This manual is applicable to vehicles

beginning with the Vehicle Identification
Numbers (VIN) shown on the following
page.

Title

Section

GENERAL INFORMATION

I

CONSTRUCTION

II

PANEL REPLACEMENT

III

WATER-PROOF AND RUST PREVENTIVE
TREATMENT

IV

DIMENSIONS

V

PLASTIC BODY PARTS

VI

PRIMARY COLOR MIXTURE CHART FOR
BODY COLORS

VII

© 2002 Mazda Motor Corporation

PRINTED IN THE NETHERLANDS, March 2002
3360–1E–02C

VEHICLE IDENTIFICATION NUMBERS (VIN)

European (L.H.D.) specs.

JMZ GG1232

✻

✻

✻

✻# 100001—

JMZ GG1282

✻

✻

✻

✻# 100001—

JMZ GG12F2

✻

✻

✻

✻# 100001—

JMZ GG12F5

✻

✻

✻

✻# 100001—

JMZ GG1432

✻

✻

✻

✻# 100001—

JMZ GG1482

✻

✻

✻

✻# 100001—

JMZ GG14F2

✻

✻

✻

✻# 100001—

JMZ GG14F5

✻

✻

✻

✻# 100001—

U.K. specs.

JMZ GG12820#

100001—

JMZ GG12F20#

100001—

JMZ GG12F50#

100001—

JMZ GG14320#

100001—

JMZ GG14820#

100001—

JMZ GG14F20#

100001—

JMZ GG14F50#

100001—

GCC specs.

JM7 GG32F

✻✻

✻✻

✻✻

✻✻# 100001—

JM7 GG42F

✻✻

✻✻

✻✻

✻✻# 100001—

JM7 GG34F

✻

✻

✻

✻✻

✻

✻

✻# 100001—

JM7 GG44F

✻

✻

✻

✻✻

✻

✻
