Mazda 6. Manual - part 396
TD–10
TECHNICAL DATA
BODY ELECTRICAL SYSTEM
A6E931001047W01
End Of Sie
HEATER AND AIR CONDITIONER SYSTEMS
A6E931001038W01
End Of Sie
Item
Specifications
Exterior light bulb capacity
(W)
Headlight
Low beam
Halogen type
55
× 2
Discharge type
35
× 2
High beam
55
× 2
Parking light
5
× 2
Front fog light
55
× 2
Front turn light
21
× 2
Front side turn light
5
× 2
Brake light/taillight
21/5
× 2
Rear turn light
21
× 2
Back-up light
18.4
× 2
Rear fog light
21
× 1
License plate light
5
× 2
High-mount brake
light
4SD
In-vehicle-type
18.4
× 1
Rear spoiler
type
4
× 1
5HB
21
× 1
Interior light bulb capacity
(W)
Front map light
5
× 2
Rear map light
5
× 2
Trunk compartment light
5
× 1
Cargo compartment light
5
× 1
Courtesy light
5
× 2
Ignition key illumination
1.4
× 1
Ashtray illumination
1.4
× 1
Glove compartment light
1.7
× 1
Item
Specification
REFRIGERANT SYSTEM
Refrigerant
Type
R–134a
Regular amount L.H.D.
470 {16.6}
(g {oz}) R.H.D.
430 {15.2}
BASIC SYSTEM
A/C compressor
Lubricating oil
Type
ATMOS GU10
Sealed volume
120 {120, 4.06}
(ml {cc, fl oz})
CONTROL SYSTEM
Magnetic clutch
Clearance
(mm {in})
0.3—0.5 {0.012—0.019}
