S–18
SEAT
FRONT SEAT
A6E775257100T03
Outline
•
Three types of seats are available.
— Manual seat with seat lifter (Driver’s side)
— Manual seat without seat lifter (Passenger’s side)
— Power seat (Driver’s side)
•
A lumber support has been adopted for driver’s seat.
•
The function and operation of the power seat is basically the same as the current MELLENIA (TA) model.
Structural View
.
End Of Sie
REAR SEAT
A6E775257200T01
Outline
•
An easy fold-down function has been adopted.
•
Child restraint seat anchors have been adopted. There are two types of anchors used for child restraint
systems: the ISOFIX and tether strap anchors.
Caution
•
Installation procedure varies with the type of child restraint seat. When installing a child restraint
seat, be sure to follow the prescribed procedure for each type.
•
A child restraint seat using a tether strap cannot be completely secured with only the tether strap.
Use an ISOFIX anchor, or a rear seat belt in conjunction with the anchor used with the tether strap.
A6E7752T002
1
Power seat (Driver’s side)
2
Manual seat with seat lifter (Driver’s side)
3
Manual seat without seat lifter (Driver’s side)
4
Slide motor (With power seat)
5
Rear tilt motor (With power seat)
6
Front tilt motor (With power seat)
7
Recliner motor (With power seat)
8
Power seat switch (With power seat)
9
Lumber support lever (Driver’s side only)
10
Seat lifter lever (Driver’s side only)
