Tightening Torques and Sequence – Intake and Exhaust Manifolds
115
Notes
V6 (X-TYPE) Engine
LH Exhaust Manifold
RH Exhaust Manifold
Intake Manifold
1. Tighten studs to 10 Nm
2. Tighten nuts in sequence shown
to 20 Nm
1. Tighten studs to 10 Nm
2. Tighten nuts in sequence shown
to 20 Nm
1. Tighten in sequence shown to 10 Nm
(Use same sequence for the 2.0 liter
gasoline engine manifold)
To convert Nm to lbf ft:
Divide the Nm torque figure by 1.356
