Index Jaguar Jaguar X-Type Sedan and Estate (Wagon) (2.0 L, 2.5 L and 3.0 L Gasoline; 2.0 L and 2.2 L, Diesel) - manual 2001-2009 year
|
|
3. Install the transaxle retaining bolts. Tighten to 48 Nm. 4. Attach the turbocharger oil feed pipe retaining bracket. Tighten to 22 Nm. 5. Remove the special tool. Remove the special tool securing strap. 6. Lower the vehicle. 7. Using the special tool raise the powertrain assembly. Adjust the engine support bracket to align the transaxle to the |
