Iveco EuroCargo (12 to 26 t). Manual - part 140

E

URO

C

ARGO

T

ECTOR

12-26 t

10

FRONT AND REAR MECHANICAL SUSPENSIONS

Base - February 2003

mm

Parabolic leaf springs

N

o

2

L

Main leaf and second leaf length

(measured at eye centre)

1758

± 3

S

Leaf thickness

1

st

leaf (measured in the middle)

2

nd

- 3

rd

- 4

th

leaf (measured in the middle)

19
21

S

Thickness between leaves

3

L

Width of leaves

80

± 0.5

NEW SPRING CHECK DATA:

Static load deflection

Static load flexibility

2

5.53 mm/kN

D

Main leaf eye internal diameter

(bushing housing)

55.5 + 0.1

D

d

D = bushing external diameter

57.3

+ 0.6

- 0.2

d = bushing internal diameter

20.2

+ 0.3

- 0

E

URO

C

ARGO

T

ECTOR

12-26 t

FRONT AND REAR MECHANICAL SUSPENSIONS

11

Base - February 2003

mm

Semi-elliptical leaf springs

N

o

2

L

Main leaf and second leaf length

(measured at eye centre)

1758

± 3

S

Leaf thickness

(measured in the middle)

14

L

Width of leaves

80

± 0.5

NEW SPRING CHECK DATA:

Static load deflection

Static load flexibility

12

6.31 mm /kN

D

Main leaf eye internal diameter

(bushing housing)

55.5

+0.1

-0

D

d

D = bushing external diameter

57.3

+0.6

-0.2

d = bushing internal diameter

20.2

+0.3

-0

E

URO

C

ARGO

T

ECTOR

12-26 t

12

FRONT AND REAR MECHANICAL SUSPENSIONS

Base - February 2003

mm

Semi-elliptical leaf springs

N

o

2

L

Main leaf and second leaf length

(measured at eye centre)

1758

± 3

S

Leaf thickness

(measured in the middle)

13

L

Width of leaves

80

± 0.5

NEW SPRING CHECK DATA:

Static load deflection

Static load flexibility

6.5

6.11 mm /kN

D

Main leaf eye internal diameter

(bushing housing)

55.5 + 0.1

D

d

D = bushing external diameter

57.3

+0.6

-0.2

d = bushing internal diameter

20.2

+0.3

-0

E

URO

C

ARGO

T

ECTOR

12-26 t

FRONT AND REAR MECHANICAL SUSPENSIONS

13

Base - February 2003

mm

Semi-elliptical leaf springs

N

o

2

L

Main leaf and second leaf length

(measured at eye centre)

1758

± 3

S

Leaf thickness

(measured in the middle)

16.5

L

Width of leaves

80

± 0.5

NEW SPRING CHECK DATA:

Free spring pointer

Flexibility

35

3.97 mm /kN

D

Main leaf eye internal diameter

(bushing housing)

55.5

+0.1

-0

D

d

D = bushing external diameter

57.3

+0.6

-0.2

d = bushing internal diameter

20.2

+0.3

-0
