Iveco EuroCargo (12 to 26 t). Manual

33611

33613

33612

Figure 40

Figure 41

Figure 42

Assemble shoulder rings, placing them into their own seat and
reverse gear (1) with the cylindrical roller bearing. Assemble
reverse gear supporting shaft with a suitable beater.

Assemble elastic peg (1).

Assemble cover (1) by tightening the screws at the required
torque.

Figure 43

33614

Slightly heat ball bearing half-race and assemble it into its own
seat on primary shaft. Assemble the odometer controlling
phonic wheel (1).

Figure 44

33615

Assemble rear cover (1), completed with sealing gasket, by
tightening the securing screws at the required torque.
Assemble motion outlet flange (2).

Figure 45

33616

Assemble reaction bar 99370317 (1), motion outlet flange
locking nut (3), wrench 99355081 (2) and tighten the locking
nut at the required torque.

GEARBOX 2865.6

URO

ARGO

ECTOR

12-26 t

Base - February 2003

Figure 46

Figure 47

Figure 48

33617

33554

Figure 49

Lock motion outlet flange rotation with bar 99370317, engage
a gear and with wrench 99355174 (1) tighten the ring nut on
motion inlet shaft at the required torque.

Assemble cover (1), completed with sealing gasket, on motion
inlet shaft and tighten securing screws at the required torque.
Assemble clutch disengagement lever and tighten securing
screws at the required torque.

Assemble the complete external control box (1).
Insert lubrication oil in the required amount, after about 20
min from application of LOCTITE 510 sealant.
Remove gearbox from rotating stand.

33553

33618

Tighten primary shaft (3) in a clamp. Remove coupling body
(1), 6

speed synchronising ring (4) and sliding sleeve (2) for

and 6

speed gears, recovering check springs and rollers.

33619

Remove elastic ring (1).

Figure 50

Figure 51

33620

With extractor 99341003 (1) and brackets 99341009 (2),
remove fixed 5

and 6

speed hub (4) together with

synchronising ring (3) and 5

speed coupling body (5).

GEARBOX 2865.6

URO

ARGO

ECTOR

12-26 t

Base - February 2003

33621

33622

33623

Figure 52

Figure 53

Figure 54

Remove 5

speed gear (1) and roller bearing below it.

Remove elastic ring (1).

Remove 4

speed gear (7) together with roller bearing and

bush (3) and coupling body (6) with holds 99341025 (4),
tie-rods 99341019 (2), bridge 99341003 (1) and clamp
99341015 (8). Remove synchronising ring (5).

33624

33626

33625

Remove 3

and 4

gear sliding sleeve (1) recovering check

springs and rollers.

Extract 3

and 4

speed fixed hub (2) and 3

speed

synchronising ring with holds 99341025 (5), tie-rods
99341019 (7), bridge 99341003 (1) and clamp 99341015 (6).
Remove 3

speed coupling body (4).

Remove 3

speed gear (1) and roller bearing below it.

Figure 55

Figure 56

Figure 57

GEARBOX 2865.6

URO

ARGO

ECTOR

12-26 t

Base - February 2003

33627

33628

33629

Figure 58

Figure 59

Figure 60

Turn the shaft over and extract reverse gear (5) with roller
bearing below it, shoulder ring (4) and rolling half-race (3) with
holds 99341025 (2), tie-rods 99341019 (7), bridge 99341003
(1) and clamp 99341015 (6).

Remove elastic ring (1).

Extract 1

speed gear (3) together with roller bearing and

fixed sleeve (2) for reverse gear with holds 99341023 (4),
tie-rods 99341020 (6), bridge 99341003 (1) and clamp
99341015 (5).

33630

33631

Figure 61

Figure 62

Remove coupling body (1), synchronising ring (2), elastic ring
(4) and sliding sleeve (3) for 1

and 2

speed gears recovering

rollers and springs.

Extract 2

speed (4) with roller bearing, coupling body,

synchronising ring and 1

and 2

speed fixed sleeve (5) with

holds 99341023 (3), tie-rods 99341020 (2), bridge 99341003
(1) and clamp 99341015 (6).

GEARBOX 2865.6

URO

ARGO

ECTOR

12-26 t

Base - February 2003
