GENERAL

S

TRALIS

AT/AD

Base - January 2003

Ref.

Description

1

2

3

4

5

6

7

8

9

Bed Modul

DDM

Conditioner

FFC

Body Computer

Cabin Module

PDM

Heater

RFC

73990

1

2

9

8

7

6

5

4

3

GENERAL

I.15

S

TRALIS

AT/AD

Instruments Cluster Bus ICB communication line

Enable dialog between the center located on the steering column and the BODY COMPUTER, CLUSTER. All informa-
tion from the steering wheel can thus reach user equipment.

Technical features

-

Data transmission speed in BIT/SEC

250,000

-

Number of ECUs connected

3

÷ 7

-

Cable colour

green

50246

I.C.

I.C.B.

B.C.

S.W.I.

I.16

GENERAL

S

TRALIS

AT/AD

Base - January 2003

73756A

A.

Ins

trument

Clus

ter

(IC)

-

B.

Steering

W

heel

Interface

(SWI)

-

E.

Body

Computer

AB

E

GENERAL

I.17

S

TRALIS

AT/AD

”ICB” components on the vehicle

Ref.

Description

1

2

3

SWI center

Cluster

Body Computer

73992

1

2

3
