DIAGRAM FOR THE INSTALLATION OF FAN BELTS - WATER PUMP - ALTERNATOR AND CONDITIONER COMPRESSOR 1. Alternator - 2. Fan - 3. Water pump - 4. Crankshaft - 5. Conditioner compressor Complete the engine by installing or connecting the following - thermostatic unit; - belt tensioner, water pump, alternator; - control belt; - belt tensioner, conditioner compressor; - control belt. Figure 186 Figure 187 44921 47564 To install belts (1-3), use the appropriate tools (2-4,) to work 84377 Fit the distribution cover (1). Fit the blow-by case (7) and its gasket and then tighten the ! The filter (5) operation is unidirectional, therefore it Fit the cover (3) and tighten the fastening screws (2) to the ! Apply silicone LOCTITE 5699 on the blow-by case 84392 Apply silicone LOCTITE 5699 on the blow-by case and form ∅ 1.5 ±, as shown in the figure. ! Fit the blow-by case (1) within 10’ from sealer Figure 188 Figure 189 0.5 90 ENGINE F2B S TRALIS AT/AD Base - January 2003 |
