Iveco Daily. Manual - part 439





282

ELECTRIC/ELECTRONIC SYSTEM

D

AILY

Base - May 2004

Closing

Press open/close push

button

Yes

Engine start in closing

Position and speed control with engine encoder

Ramp start

Constant speed travel to next stage

Complete closing

Yes

Center cut out

Engine cut out

Micro switch complete

opening position engaged?

No

Encoder reading of door

nearly closed

Deceleration

Micro switch engaged on lock

No

Reposition

on opening

ELECTRIC/ELECTRONIC SYSTEM

283

D

AILY

Operating diagram

REMOTE

CONTROL

CLOSES

MECHANICAL

KEY OPENS

REMOTE

CONTROL

OPENS

OPERATOR door

ROTO door

LOCKED
CLOSED

OPERATOR door

ROTO door

UNLOCKED
CLOSED

INSTRUMENT

PANEL PUSH

BUTTON

OPENS

REMOTE

CONTROL

OPENS

OPERATOR door

ROTO door

UNLOCKED
OPEN

EMERGENCY

HANDLE.

REMOTE

CONTROL

CLOSES

INSTRUMENT

PANEL PUSH

BUTTON

CLOSES

LOCKED
OPEN

REMOTE

CONTROL

OPENS

UNLOCKED
OPEN

REMOTE

CONTROL

CLOSES

UNLOCKED
CLOSED

INSTRUMENT

PANEL PUSH

BUTTON

CLOSES

UNLOCKED
CLOSED

REMOTE

CONTROL

CLOSES

MECHANICAL

KEY

LOCKED
CLOSED

N.B.: As a consequence of use by

IVECO of passive type door locks,

disconnected operation may occur

between operator and rotating sliding

door opening and closing.

OPERATOR door

ROTO door

OPERATOR door

ROTO door

OPERATOR door

ROTO door

OPERATOR door

ROTO door

OPERATOR door

ROTO door

284

ELECTRIC/ELECTRONIC SYSTEM

D

AILY

Base - May 2004

- Remove the snap-fitted panel (Ref. A) to gain access to

the panel fastening screws (Ref. B).

- Slacken the 4 fastening screws, two on either side, of the

lower panel (Ref. A).

Electronic  tachograph  control  unit  housing

assembly

Fasten  the  control  unit  to  the  support,  insert  the  3

connectors, eliminating the bridges between the connectors

(white, yellow and brown) and apply the seals (ref. A).

B

A

A

A

LOWER DASHBOARD SNAP-FITTED PANEL

LOWER PANEL FASTENING SCREWS

LOWER PANEL FASTENING SCREWS

CONNECTIONS AND TACHOGRAPH CONTROL

UNIT SUPPORT

A

Figure 328

Figure 329

Figure 330

Figure 331

8782

8783

8781

8670

ELECTRIC/ELECTRONIC SYSTEM

285

D

AILY

Assembling  the  tachograph  control  unit

support on the dashboard

Use  the  six  screws  to  fasten  the  tachograph  control  unit

support to the dashboard.

TACHOGRAPH CONTROL UNIT

TACHOGRAPH CONTROL UNIT FASTENING TO

DASHBOARD

TACHOGRAPH CONTROL UNIT SUPPORT FASTENING SCREWS

Figure 332

8784

8785

8786

Figure 333

Figure 334
