HYDRO-PNEUMATIC SYSTEM - BRAKES

D

AILY

Base - May 2004

DESCRIPTION

SYMBOL

COMPRESSED AIR TANK

BRAKE FLUID RESERVOIR

AIR SPRING

32791

32790

HYDRO-PNEUMATIC SYSTEM - BRAKES

11

D

AILY

Base - May 2004

DESCRIPTION

SYMBOL

VACUUM SERVO BRAKE

VACUUM SERVO BRAKE

DUAL CIRCUIT MASTER CYLINDER

SINGLE CIRCUIT MASTER CYLINDER

AIR/HYDRAULIC CONVERTER

AIR/HYDRAULIC CONVERTER

HYDRAULIC BRAKE CYLINDER

SLAVE CYLINDER

BRAKE CYLINDER

SPRING CYLINDER

COMBINED BRAKE CYLINDER

FIXED DISK BRAKE CALIPER

32791

12

HYDRO-PNEUMATIC SYSTEM - BRAKES

D

AILY

Base - May 2004

DESCRIPTION

SYMBOL

FLOATING DISK BRAKE CALIPER

FLOATING

DISK

BRAKE

CALIPER

WITH PARKING

MECHANICAL FLOATING DISK BRAKE
CALIPER

SERVO CLUTCH

SERVO CLUTCH

32793

32792

HYDRO-PNEUMATIC SYSTEM - BRAKES

13

D

AILY

Base - May 2004

DESCRIPTION

SYMBOL

”ISO” SEMICOUPLING

A

M

ISO VERSION

”ISO” SEMICOUPLING

A

M

ISO JOINT VERSION

”CUNA” SEMICOUPLING

A

B

ITALY VERSION

”CUNA” SEMICOUPLING

M

A

”NATO” SEMICOUPLING

A

M

NATO VERSION
