70

REAR MECHANICAL SUSPENSIONS

D

AILY

Rear leaf spring
Vehicles:

50 C

mm

Parabolic springs

N

o

2

L

Spring length

(measured at eye centres)

1415

± 3

S

Leaf thickness (measured at the centre)

master leaf

22 (24)*

S

Gap between leaves

3 (10)*

L

Leaf width

60

± 0.5

CONTROL DATA WITH NEW SPRING:

Main spring flexibility with static load

5.6 mm/kN

D

Main leaf eye inner diameter

(Bush seat)

40

± 0.5

D

d

D = bush outer diameter

40

+0

−0.1

d = bush inner diameter

16.5

+0.2

−0

(*) Alternatively

REAR MECHANICAL SUSPENSIONS

71

D

AILY

Rear leaf spring
Vehicles:

60 C - 65 C

mm

Semi-elliptical springs

N

o

2

L

Spring length

(measured at centre of eyes)

1415

± 4

S

Leaf thickness (measured at the centre),

master leaf (1st - 4th)

additional leaf (1st - 2nd)

11
22

S

Gap between leaves

--

L

Leaf width

70

± 0.5

CONTROL DATA WITH NEW SPRING:

Main spring flexibility with static load

Flexibility with static load after aux. spring action

9.3 mm/kN
3.1 mm/kN

D

Main leaf eye inner diameter

(Bush seat)

40

+0.5

−0.2

D

d

D = bush outer diameter

40

+0.02

−0.07

d = bush inner diameter

16.5

+0.2

−0

72

REAR MECHANICAL SUSPENSIONS

D

AILY

Rear leaf spring
Vehicles:

60 C - 65 C (semi-elliptical with leaf spring)

mm

Semi-elliptical springs

N

o

2

L

Spring length

(measured at centre of eyes)

1415

S

Leaf thickness (measured at the centre),

master leaf (1st - 10th)

auxiliary leaf thickness (1st - 10th)

9
7

S

Gap between leaves

9

L

Leaf width

70

± 0.5

CONTROL DATA WITH NEW SPRING:

Main spring flexibility with static load

Flexibility with static load after aux. spring action

8.5 mm/kN
2.4 mm/kN

D

Main leaf eye inner diameter

(Bush seat)

40

+0.5

−0.2

D

d

D = bush outer diameter

40

+0.02

−0.07

d = bush inner diameter

16.5

+0.2

−0

(*) Alternatively

REAR MECHANICAL SUSPENSIONS

73

D

AILY

Rear shock absorbers

Models:

29 L - 35 S

Arvin Meritor

Sachs

Distance between centre of eyes:

Open

475

± 3 mm

480

± 3 mm

Closed

302

± 3 mm

300

± 3 mm

Stroke

173 mm

180 mm

Models:

35 C - 40 C - 45 C - 50 C

Arvin Meritor

Sachs

Distance between centre of eyes:

Open

571

± 3 mm

565

± 3 mm

Closed

350

± 3 mm

345

± 3 mm

Stroke

221 mm

220 mm

Models:

60 C - 65 C

Arvin Meritor

Sachs

Distance between centre of eyes:

Open

564

± 3 mm

565

± 3 mm

Closed

347

± 3 mm

345

± 3 mm

Stroke

217 mm

220 mm

Rear stabilizer bar

Models:

29 L - 35 S - 35 C - 40 C

45 C - 50 C

Vans

45 C - 50 C

Truck

Chassis Cabs

60 C - 65 C

Stabilizer bar diameter

(mm)

18

20

22

28
