48 6 S 300 TRANSMISSION D AILY Base - May 2004 SPECIFICATIONS AND DATA TRANSMISSION 6 S 300 Type Mechanical Input torque 320 Nm Weight 63 kg Speeds 6 forward speeds 1 reverse speed Speed control Mechanical Power take-off Optional Speed engagement: Forward speeds - 5 th /6 th - 3 rd /4 th Single-cone synchronizer - 1 st /2 nd Dual-cone synchronizer Reverse speed clip-on, in new version transmission with single taper synchroniser ring Speed retention mechanism Sliding sleeves retained by pawls and springs Gears Helical-toothed constant mesh gears Gear ratio First 6.72 Second 3.94 Third 2.55 Fourth 1.77 Fifth 1.29 Sixth 1.00 Reverse 6.05 Shaft bearings: Main shaft Transmission shaft watertight ball bearing tapered roller |
