6A – 162 ENGINE MECHANICAL
Important Operations
2. Relief
Valve
Tighten the relief valve to the specified torque.
Relief Valve Torque
kg·m (lb.ft/N·m)
3.0
± 0.5 (21.7 ± 3.6/29.4 ± 4.9)
5. Oil
Cooler
1) Align the oil filter holes with the body knock pins at
installation.
2) Tighten the oil cooler nut to the specified torque.
Oil Cooler Nut Torque
kg·m (lb.ft/N·m)
3.0
± 0.5 (21.7 ± 3.6/29.4 ± 4.9)
6. Oil Filter Cartridge
1) Apply engine oil to the O-ring.
2) Turn in the cartridge oil filter until the filter sealing face
makes contact with the O-ring.
3) Turn in the cartridge oil filter an additional one and 1/8
of a turn.
7. Drain
Plug
Tighten the drain plug to the specified torque.
Drain Plug Torque
kg·m (lb.ft/N·m)
2.5
± 0.5 (18.1 ± 3.6/24.5 ± 4.9)
