Isuzu D-Max / Isuzu Rodeo (TFR/TFS). Manual - part 1913
7A4-84 UNIT REPAIR (JR405E)
SERVICE STANDARD (Cont’d)
Number of coil
4.8
Outside diameter
mm (in)
11.2
(0.441)
Free length
mm (in)
22.3
(0.878)
Return
spring
Linear diameter
mm (in)
1.1
(0.043)
Number of drive / driven plate
5/5
Standard mm
(in)
2.0
(0.079)
Drive plate facing thickness
Limit mm
(in)
1.8
(0.071)
Retaining plate and retaining plate clearance
mm (in)
1.0 – 1.4
(0.039 – 0.055)
5.4 (0.213)
5.6 (0.220)
5.8 (0.228)
6.0 (0.236)
6.2 (0.244)
Available 2-4 brake retaining plate thickness
mm (in)
6.4 (0.252)
Number of coil
10.2
Outside diameter
mm (in)
6.9
(0.272)
Free length
mm (in)
22.5
(0.886)
2-4 brake
Return spring
Linear diameter
mm (in)
1.1
(0.043)
Output shaft
Seal ring clearance
mm (in) 0.10 – 0.25 (0.0039 – 0.0098)
Total end play
mm (in) 0.25 – 0.55 (0.0098 – 0.0217)
1.4 (0.055)
1.6 (0.063)
1.8 (0.071)
2.0 (0.079)
2.2 (0.087)
Total end play
Available oil pump bearing race thickness
mm (in)
2.4 (0.094)
Torque converter end play
mm (in)
67.0
(2.638)
