8–240 ELECTRICAL-BODY AND CHASSIS

W/ Tachometer (Gasoline engine)

Illumination light

Reset  knob

Warning  light  lens

Warning  light  lens

Tachometer

Engine  coolant
temperature  gauge

Fuel  gauge

Speedometer

+

-

(Tachometer,6VD1)

D08RW556

(This illustration is based on the Km/h meter)

ELECTRICAL-BODY AND CHASSIS 8–241

W/ Tachometer (Diesel engine)

Illumination light

Reset  knob

Warning  light  lens

Warning  light  lens

Tachometer

Engine  coolant
temperature  gauge

Fuel  gauge

Speedometer

+

-

T BELT

826RV032

(This illustration is based on the Km/h meter)

8–242 ELECTRICAL-BODY AND CHASSIS

Meter connector pin arrangement

W/O Tachometer (Gasoline engine)

1 2 3 4 5 6 7 8 9

10 11 12 13 14 15 16

1 2 3 4 5 6 7

8 9 10 11 12 13 14 15 16

BLACK

B-24

B-23

WHITE

Connector

Ter-

No.

minal No.

1

Ground

2

Ignition

3

—

4

—

5

—

6

Engine coolant temperature gauge

7

—

8

—

9

Oil temp. warning light (Saudi Arabia
only)
Check engine warning light

10

Seat belt warning light (Saudi Arabia
only)
Diff. lock indicator light (South Africa
only)

11

High-beam indicator light (+)

12

High-beam indicator light (–)

13

Illumination light (+)

14

Illumination light (–)

15

4WD indicator light

16

Turn signal indicator light (left)

B-24

Connector

Ter-

No.

minal No.

1

Turn signal indicator light (right)

2

—

3

—

4

—

5

Ground

6

—

7

Ignition

8

Speedometer

9

Speedometer

10

Oil pressure warning light

11

Fuel gauge

12

Brake warning light

13

Charge warning light

14

—

15

—

16

Fuel warning light

B-23

826RV038

ELECTRICAL-BODY AND CHASSIS 8–243

Meter connector pin arrangement

W/O Tachometer (Diesel engine)

1 2 3 4 5 6 7 8 9

10 11 12 13 14 15 16

1 2 3 4 5 6 7

8 9 10 11 12 13 14 15 16

BLACK

B-24

B-23

WHITE

Connector

Ter-

No.

minal No.

1

Ground

2

Ignition

3

—

4

—

5

—

6

Engine coolant temperature gauge

7

—

8

Glow indicator light

9

Sedimenter warning light

10

Seat belt warning light (Saudi Arabia
only)
Diff. lock indicator light (South Africa
only)

11

High-beam indicator light (+)

12

High-beam indicator light (–)

13

Illumination light (+)

14

Illumination light (–)

15

4WD indicator light

16

Turn signal indicator light (left)

B-24

Connector

Ter-

No.

minal No.

1

Turn signal indicator light (right)

2

—

3

—

4

—

5

Ground

6

—

7

Ignition

8

Speedometer

9

Speedometer

10

Oil pressure warning light

11

Fuel gauge

12

Brake warning light

13

Charge warning light

14

—

15

—

16

Fuel warning light

B-23

826RV037
