8–176 ELECTRICAL-BODY AND CHASSIS

WARNING BUZZER (SOUTH AFRICA)

1. Warning Buzzer Circuit

Warning function

Operational conditions

The buzzer sounds when the starter switch is turned on with the seat
belt switch on (when the seat belt is not used).

The buzzer sounds when both the key remind switch and the FRT
door switch-LH are turned on.
To stop the sound of the buzzer, turn on the starter switch.

The buzzer sounds when the starter switch is turned from the “on”
to “off” position while the taillights are on.

Terminal

Wire

Connecting to

Check item

Connecting

Check condition

Standard

No.

color

terminal

5

G/Y

Seat belt SW

Continuity

5-Ground

Seat

Unfasten

Continuity

belt

Fasten

No continuity

3

G/R

Tail relay

3-Ground

Lighting SW “ON”

Approx. 12V

4

R/B

Key remind SW

Voltage

4-Ground

Key

Insert

Approx. 12V

(Starter SW)

Remove

0V

6

Y

Fuse CB-7

6-Ground

Starter SW “ON”

Approx. 12V

1

B/W

Door SW

1-Ground

FRT door-LH

Open

Continuity

(FRT-LH)

Continuity

Close

No continuity

2

B

Ground

2-Ground

—

Continuity

Door
SW
(FRT
  -LH)

Seat
belt
SW

Key remind SW

Tail relay

Starter SW

Warning buzzer

2

5

1

＋

−

6

4

3

D08RV990

Fasten the seat belt

Key left in starter switch

Taillights left on

ELECTRICAL-BODY AND CHASSIS 8–177

2. Warning Buzzer Harness Side Connector Circuit

Disconnect the warning buzzer connector and check
continuity and voltage between the warning buzzer
harness side connector terminals.

1

2

3

6

4 5

B-5

Harness side

Terminal

Wire

Connecting to

Check item

Connecting

Check condition

Standard

No.

color

terminal

5

G/Y

Seat belt SW

Continuity

5-Ground

Seat

Unfasten

Continuity

belt

Fasten

No continuity

3

G/R

Tail relay

3-Ground

Lighting SW “ON”

Approx. 12V

4

R/B

Key remind SW

Voltage

4-Ground

Key

Insert

Approx. 12V

(Starter SW)

Remove

0V

6

Y

Fuse CB-5

6-Ground

Starter SW “ON”

Approx. 12V

1

B/W

Door SW

1-Ground

FRT door-LH

Open

Continuity

(FRT-LH)

Continuity

Close

No continuity

2

B

Ground

2-Ground

—

Continuity

KEY REMIND SWITCH (STARTER SWITCH)

Switch Connections

1

2

3

4

5

6

7

8

C-41

730RV001

Connector No.

C-41

Starter

Terminal

switch key position

No.

5

7

LOCK

Removed

OFF

ACC

Inserted

ON

START

8–178 ELECTRICAL-BODY AND CHASSIS

WINDSHIELD WIPER AND WASHER

PARTS LOCATION (LHD)

C-4

C-3

C-17

C-41
C-43

H-8

C-36

C-2

H-7

D08RVA36

ELECTRICAL-BODY AND CHASSIS 8–179

PARTS LOCATION (RHD)

C-36

C-2

C-4

C-3

C-17

C-41
C-43

H-6
H-7

D08RVA35
