8–24 ELECTRICAL-BODY AND CHASSIS

RELAY AND FUSE BOX, FUSE BOX LOCATION
LHD-2 (6VD1)

D08RW522

D08RW613

D08RW555

Relay and fuse box

Fuse box

FUSE BOX

ELECTRICAL-BODY AND CHASSIS 8–25

RHD-1

D08RV925

安田

E3110 8

'9

'9

発注者

受注番号

発注日

希望納期

4556

作業番号

FUSE BOX

RELAY & FUSE BOX

8–26 ELECTRICAL-BODY AND CHASSIS

RHD-2 (6VD1)

D08RW522

D08RW554

Fuse box

Relay and fuse box

FUSE BOX

D08RW614

ELECTRICAL-BODY AND CHASSIS 8–27

FUSE AND FUSIBLE LINK LOCATION-1 (RELAY AND FUSE BOX)

RELAY & FUSE BOX

EB-1

EB-8

EB-2

EB-9

EB-3 EB-10
EB-4 EB-11

EB-5 EB-12

EB-6 EB-13
EB-7 EB-14

EB-17

EB-18 EB-16 EB-15

EB-19

D08RV811

Engine

model

4Z Series

4ZD1 (MPI)

4ZE1 (MPI)

4J Series

4JA1

NO.

(South Africa)

EB-1

15A HAZARD

15A HAZARD

15A HAZARD

15A HAZARD

15A HAZARD

EB-2

10A HORN

10A HORN

10A HORN

10A HORN

10A HORN

EB-3

—

—

—

—

—

EB-4

20A BLOWER

20A BLOWER

20A BLOWER

20A BLOWER

20A BLOWER

EB-5

10A AIR CON.

10A AIR CON.

10A AIR CON.

10A AIR CON.

10A AIR CON.

EB-6

—

—

10A (RR FOG)

—

—

EB-7

—

10A O

2

SENSOR 10A (O

2

SENSOR)

10A (CHARGE)

—

EB-8

10A H/LAMP-LH

10A H/LAMP-LH 10A H/LAMP-LH

10A H/LAMP-LH

10A H/LAMP-LH

EB-9

10A H/LAMP-RH

10A H/LAMP-RH 10A H/LAMP-RH

10A H/LAMP-RH

10A H/LAMP-RH

EB-10

—

—

—

—

—

EB-11

10A STOP

10A STOP

10A STOP

10A STOP

10A STOP

EB-12

15A TAIL

15A TAIL

15A TAIL

15A TAIL

15A TAIL

EB-13

—

15A ECM

15A ECM

—

—

EB-14

10A AUTO CHOKE 20A FUEL PUMP

20A FUEL PUMP

—

—

FUSE

Engine

model

4Z Series

4ZD1 (MPI)

4ZE1 (MPI)

4J Series

4JA1

NO.

(South Africa)

EB-15

40A IGN. B1

40A IGN. B1

40A IGN. B1

40A IGN. B1

40A IGN. B1

EB-16

80A MAIN

80A MAIN

100A MAIN

100A MAIN

80A MAIN

EB-17

—

—

—

50A GLOW

50A GLOW

EB-18

30A (EFE)

—

30A(H/LAMP WASHER)

—

—

EB-19

40A IGN. B2, POWER 40A IGN. B2, POWER 40A IGN. B2, POWER

40A IGN. B2, POWER 40A IGN. B2, POWER

FUSIBLE LINK
