ELECTRICAL-BODY AND CHASSIS  8-29

RELAY LOCATION-1 (RELAY AND FUSE BOX)

RELAY & FUSE BOX

RELAY (HEC)

NO.

HEC Engine Series

NO.

HEC Engine Series

X-1

RELAY;HEAD LIGHT

X-16 (RELAY;COND.FAN)

X-2

RELAY;TAIL LIGHT

X-17

-

X-3

RELAY;HEATER

X-4

RELAY;HORN

X-6

RELAY;STARTER

X-7

(RELAY;THERMO)

X-9

RELAY;FUEL PUMP

X-15 (RELAY;A/C COMP)

RELAY (6VD1)

NO.

6VD1 Engine Series

NO.

6VD1 Engine Series

X-1

RELAY;HEAD LIGHT

X-16 RELAY;COND.FAN

X-2

RELAY;TAIL LIGHT

X-17

-

X-3

RELAY;HEATER

X-4

RELAY;HORN

X-6

RELAY;STARTER

X-7

RELAY;THERMO

X-9

RELAY;FUEL PUMP

X-15 RELAY;A/C COMP

RELAY (4J)

NO.

4J Engine Series

NO.

4J Engine Series

X-1

RELAY;HEATER

X-9

RELAY;HEAD LIGHT

X-2

RELAY;CHARGE

X-10 RELAY;QWS

X-3

RELAY;HORN

X-11 RELAY;RR FOG

X-4

-

X-12 RELAY;DIMMER

X-5

RELAY;IMMOBILIZER X-13 RELAY;STARTER

X-6

RELAY;TAIL LIGHT

X-7

-

X-8

RELAY;THERMO



8-30  ELECTRICAL-BODY AND CHASSIS

RELAY LOCATION-2 (HEC ENGINE MODEL)

(LHD)

(RHD)




RELAY

Connector

No. C-3 C-45  B-5  B-7  B-8

HEC Engine Series  WINDSHIELD

INTERMITTENT

FLASHER UNIT KEY, LIGHT AND

SEAT BELT
REMIND
BUZZER (For
Gulf only)

REAR
DEFOGGER

(Except South
Africa & Chile)

POWER
WINDOW

ELECTRICAL-BODY AND CHASSIS  8-31

Gulf only)

RELAY LOCATION-3 (4J ENGINE MODEL)

(LHD)

(RHD)

C-45

C-3

Flasher unit

B-5

Key, light and seat belt

remind buzzer

Relay;Intermittent

Relay;Glow-1

Relay;Glow-2

C-49

C-50

Relay;Rear defogger

B-7

Relay;Power window

B-8




RELAY

Connector

No. C-3 C-45  B-5  B-7  B-8

4J Engine Series

WINDSHIELD
INTERMITTENT

FLASHER UNIT KEY, LIGHT AND

SEAT BELT
REMIND

REAR
DEFOGGER

POWER
WINDOW

8-32  ELECTRICAL-BODY AND CHASSIS

BUZZER




RELAY LOCATION-4 (6VD1 ENGINE MODEL)

(LHD)

(RHD)




RELAY

Connector

No. C-3 C-45  B-5  B-7  B-8

Relay  WINDSHIELD

INTERMITTENT

FLASHER UNIT KEY, LIGHT AND

SEAT BELT

REAR
DEFOGGER

POWER
WINDOW
