CAB 10-21 13.Window Glass • First, align the height of regulator to the access hole. Remove 2 screws attaching bottom channel and regulator, then remove the glass. • Remove the window glass by tilting it as necessary. 17.Door Lock Assembly • Disconnect the linkage from the door outside handle, inside lever and lock cylinder. Remove the 2 bolts holding the outside handle from inner side. • Remove the 3 bolts holding the door lock assembly. |
