Isuzu D-Max / Isuzu Rodeo (TFR/TFS). Manual - part 1012

10-48  CAB

FRONT SEAT BELT



  REMOVAL AND INSTALLATION

Removal Steps

1. Trim
2. Seat belt and retractor

Installation Steps

V

2. Seat belt and retractor
1. Trim

Important Operation - Installation

2. Seat Belt and Retractor

Bolt Torque

N

⋅

m(kgf

⋅

m/lb

⋅

ft)

39.2

±

 9.8 (4

±

 1 / 28.9

±

 7.2)

CAB  10-49

REAR SEAT BELT



  REMOVAL AND INSTALLATION

Removal Steps

1. Trim
2. Rear seat belt and retractor
3. Rear seat cushion
4. Center belt and buckle

Installation Steps

V

4. Center seat belt and buckle
3. Rear seat cushion

V

2. Rear seat belt and retractor
1. Trim

Important Operation - Installation

2. Rear Seat Belt and Retractor

Bolt Torque

N

⋅

m(kgf

⋅

m/lb

⋅

ft)

39.2

±

 9.8 (4

±

 1 / 28.9

±

 7.2)

4. Center back Belt and buckle

Bolt Torque

N

⋅

m(kgf

⋅

m/lb

⋅

ft)

39.2

±

 9.8 (4

±

 1 / 28.9

±

 7.2)

10-50  CAB

JUMP SEAT



  REMOVAL AND INSTALLATION

Removal Steps

1. Head rest and back trim cover
2. Hinge cover, center
3. Bolt
4. Jump seat assembly

Installation Steps

4. Jump seat assembly

V

3. Bolt
2. Hinge cover ; center
1. Head rest and back trim cover

Important Operation - Installation

3. Bolt

Torque

N

⋅

m(kgf

⋅

m/lb

⋅

ft)

19.6

±

 5 (2

±

 0.5 / 14.5

±

 3.6)

CAB  10-51

JUMP SEAT BELT



  REMOVAL AND INSTALLATION

Removal Steps

1. Hinge cover
2. Hinge cover ; center
3. Bolt

Installation Steps

V

3. Bolt
2. Hinge cover ; center
1. Hinge cover

Important Operation - Installation

3. Bolt

Torque

N

⋅

m(kgf

⋅

m/lb

⋅

ft)

39.2

±

 9.8 (4

±

 1 / 28.9

±

 7.2)
