MT-8

DESCRIPTION

TRIPLE-CONE SYNCHRONIZER

The 1st, 2nd and 3rd gears is equipped with a triple-cone synchro-
nizer to reduce the operating force of the shift lever.

PCIB1432E

M/T OIL

MT-9

D

E

F

G

H

I

J

K

L

M

A

B

MT

M/T OIL

PFP:KLD20

Changing M/T Oil

NCS000AM

DRAINING

1.

Start the engine and warm up the transmission unit sufficiently.

2.

After stopping engine, remove filler plug and drain plug to drain oil.

3.

Replace gasket on drain plug with new one. Screw drain plug into transmission case, and tighten to the
specified torque. Refer to

MT-21, "Case Components"

 .

CAUTION:

Do not reuse gasket.

FILLING

1.

Fill new oil into the transmission to the level of the filler plug mounting hole.

2.

Replace gasket on filler plug with new one. Screw filler plug into transmission case, and tighten to the
specified torque. Refer to

MT-21, "Case Components"

 .

CAUTION:

Do not reuse gasket.

Checking M/T Oil

NCS000AN

OIL LEAKAGE AND OIL LEVEL

●

Check if oil is leaking from transmission or around it.

●

Check oil level from filler plug mounting hole as shown in the fig-
ure.

CAUTION:

Never start engine while checking oil level.

●

When screwing in filler plug with a new gasket, first screw into
the transmission by hand, then tighten to the specified torque.
Refer to

MT-21, "Case Components"

 .

CAUTION:

Do not reuse gasket.

Oil grade and viscosity

: Refer to

MA-10, "RECOMMENDED FLUIDS AND LUBRICANTS"

 .

Oil capacity

: Approx. 2.9  (3-1/8 US qt, 2-1/2 lmp qt)

PCIB0268E

MT-10

REAR OIL SEAL

REAR OIL SEAL

PFP:33140

Removal and Installation

NCS000AO

REMOVAL

1.

Remove propeller shaft. Refer to

PR-4, "Removal and Installation"

 .

2.

Remove rear oil seal using oil seal puller.

INSTALLATION

1.

Apply multi-purpose grease to rear oil seal lip. Drive in rear oil
seal until the edge is approximately 1.2 - 2.2 mm (0.047 - 0.087
in) above the boss edge using drift.

CAUTION:

●

Do not reuse rear oil seal.

●

When installing, do not tilt oil seal.

2.

Install propeller shaft. Refer to

PR-4, "Removal and Installation"

 .

CAUTION:

●

If lubricant leak has occurred during the repair work, check oil level after finishing work.  Refer
to

MT-9, "Checking M/T Oil"

 .

Tool number

: KV381054S0 (

—

)

PCIB0194E

Tool number

: ST33400001 (J-26082)

PCIB0267E

POSITION SWITCH

MT-11

D

E

F

G

H

I

J

K

L

M

A

B

MT

POSITION SWITCH

PFP:32005

Checking

NCS000AP

COMPONENT LOCATION

BACK-UP LAMP SWITCH

●

Check continuity.

PARK/NEUTRAL POSITION SWITCH

●

Check continuity.

PCIB1384E

Gear position

Continuity

Reverse

Yes

Except reverse

No

SCIA0645E

Gear position

Continuity

Neutral

Yes

Except neutral

No
