NAVIGATION SYSTEM

AV-87

Place

In a parking lot

When driving in a parking lot, or
other location where there are no
roads on the map, matching may
place the vehicle mark on a nearby
road. When the vehicle returns to
the road, the vehicle mark may have
deviated from the correct location.
When driving in circle or turning the
steering wheel repeatedly, direction
errors accumulate, and the vehicle
mark may deviate from the correct
location.

If after traveling about 10 km (6
miles) the correct location has not
been restored, perform location
correction and, if necessary,
direction correction.

Turn table

When the ignition switch is OFF, the
navigation system cannot get the
signal from the gyroscope (angular
speed sensor). Therefore, the dis-
played direction may be wrong and
the correct road may not be easily
returned to after rotating the vehicle
on a turn table with the ignition OFF.

Slippery roads

On snow, wet roads, gravel, or other
roads where tires may slip easily,
accumulated mileage errors may
cause the vehicle mark to deviate
from the correct road.

Slopes

When parking in sloped garages,
when traveling on banked roads, or
in other cases where the vehicle
turns when tilted, an error in the
turning angle will occur, and the
vehicle mark may deviate from the
road.

Map data

Road not displayed on the map screen

When driving on new roads or other
roads not displayed on the map
screen, map-matching does not
function correctly and matches the
location to a nearby road. When the
vehicle returns to a road which is on
the map, the vehicle mark may devi-
ate from the correct road.

Different road pattern
(Changed due to repair)

If the road pattern stored in the map
data and the actual road pattern are
different, map-matching does not
function correctly and matches the
location to a nearby road. The vehi-
cle mark may deviate from the cor-
rect road.

Vehicle

Use of tire chains

When tire chains are used, the mile-
age is not correctly detected, and
the vehicle mark may deviate from
the correct road.

Drive the vehicle for a while. If the
distance is still deviated, adjust it
by using the distance adjustment
function. (If the tire chain is
removed, recover the original
value.)

Cause (condition)

: While driving

Driving condition

Remarks (correction, etc.)

SEL709V

SEL710V

SEL699V

ELK0201D

AV-88

NAVIGATION SYSTEM

THE CURRENT POSITION MARK SHOWS A POSITION WHICH IS COMPLETELY WRONG

In the following cases, the current-location mark may appear on completely different position in the map
depending on the GPS satellite signal receiving conditions. In this case, perform location correction and direc-
tion correction.

●

When location correction has not been done

–

If the receiving conditions of the GPS satellite signal is poor, if the current-location mark becomes out of
place, it may move to a completely different location and not come back if location correction is not done.
The position will be corrected if the GPS signal can be received.

●

When the vehicle has traveled by ferry, or when the vehicle has been being towed

–

Because calculation of the current location cannot be done when traveling with the ignition OFF, for exam-
ple when traveling by ferry or when being towed, the location before travel is displayed. If the precise loca-
tion can be detected with GPS, the location will be corrected.

THE CURRENT POSITION MARK JUMPS

In the following cases, the current-location mark may appear to jump as a result of automatic correction of the
current location.

●

When map-matching has been done

–

If the current location and the current-location mark are different when map-matching is done, the current-
location mark may seem to jump. At this time, the location may be “corrected” to the wrong road or to a
location which is not on a road.

●

When GPS location correction has been done

–

If the current location and the current-location mark are different when the location is corrected using GPS
measurements, the current-location mark may seem to jump. At this time, the location may be “corrected”
to a location which is not on a road.

Precautions
for driving

Just after the engine is started

If the vehicle is driven off just after
the engine is started when the gyro-
scope (angular speed sensor) cor-
rection is not completed, the vehicle
can lose its direction and may have
deviated from the correct location.

Wait for a short while before driv-
ing after starting the engine.

Continuous driving without stopping

When driving long distances without
stopping, direction errors may accu-
mulate, and the current-location
mark may deviate from the correct
road.

Stop and adjust the orientation.

Abusive driving

Spinning the wheels or engaging in
other kinds of abusive driving may
result in the system being unable
perform correct detection, and may
cause the vehicle mark to deviate
from the correct road.

If after traveling about 10 km (6
miles) the correct location has not
been restored, perform location
correction and, if necessary,
direction correction.

How to
correct
location

Position correction accuracy

If the accuracy of location settings is
poor, accuracy may be reduced
when the correct road cannot be
found, particularly in places where
there are many roads.

Enter in the road displayed on the
screen with an accuracy of
approx. 1 mm.
Caution: Whenever possible, use
detailed map for the correction.

Direction when location is corrected

If the accuracy of location settings
during correction is poor, accuracy
may be reduced afterwards.

Perform direction correction.

Cause (condition)

: While driving

Driving condition

Remarks (correction, etc.)

SEL701V

SEL702V

NAVIGATION SYSTEM

AV-89

THE CURRENT-LOCATION MARK IS IN A RIVER OR THE SEA

The navigation system moves the current location mark with no distinction between land and rivers or sea. If
the location mark is somehow out of place, it may appear that the vehicle is driving in a river or the sea.

WHEN DRIVING ON THE SAME ROAD, SOMETIMES THE CURRENT-LOCATION MARK IS IN
THE RIGHT PLACE AND SOMETIMES IT IS IN THE WRONG PLACE

The conditions of the GPS antenna (GPS data) and gyroscope (angular speed sensor) change gradually.
Depending on the road traveled and the operation of the steering wheel, the location detection results will be
different. Therefore, even on a road on which the location has never been wrong, conditions may cause the
vehicle mark to deviate.

LOCATION CORRECTION BY MAP-MATCHING IS SLOW

●

The map-matching function needs to refer to the data of the surrounding area. It is necessary to drive
some distance for the function to work.

●

Because map-matching operates on this principle, when there are many roads running in similar direc-
tions in the surrounding area, no matching determination may be made. The location may not be cor-
rected until some special feature is found.

ALTHOUGH THE GPS RECEIVING DISPLAY IS GREEN, THE VEHICLE MARK DOES NOT
RETURN TO THE CORRECT LOCATION

●

The GPS accuracy has an error of about 10 m (30 ft). In some cases the current-location mark may not be
on the correct street, even when GPS location-correction is done.

●

The navigation system compares the results of GPS location detection with the results from map-match-
ing location detection. The one which is determined to have higher accuracy is used.

●

GPS location correction may not be performed when the vehicle is stopped.

THE NAME OF THE CURRENT PLACE IS NOT DISPLAYED

The current place name may not be displayed if there are no place names displayed on the map screen.

CONTENTS OF THE DISPLAY DIFFER FOR THE BIRD VIEW™ AND THE (FLAT) MAP SCREEN

Difference of the Bird View™ Screen From the Flat Map Screen Are as Follows.

●

The current place name displays names which are primarily in the direction of vehicle travel.

●

The amount of time before the vehicle travel or turn angle is updated on the screen is longer than for the
(flat) map display.

●

The conditions for display of place names, roads, and other data are different for nearby areas and for
more distant areas.

●

Some thinning of the character data is done to prevent the display becoming to complex. In some cases
and in some locations, the display contents may differ.

●

The same place name, street name, etc. may be displayed multiple times.
