№		Номер детали	Наименование запчасти
1		190003559507 [Union nut]	Union nut
2		190003559556 [Cutting ring]	Cutting ring
3		199014280040 [Sleeve]	Sleeve
4		190003559516 [Union nut]	Union nut
5		190003559561 [Cutting ring]	Cutting ring
6		199014280016 [Sleeve]	Sleeve
7		190003559509 [Union nut]	Union nut
8		190003559558 [Cutting ring]	Cutting ring
9		199014280041 [Sleeve]	Sleeve
10		190003559518 [Union nut]	Union nut
11		190003559564 [Cutting ring]	Cutting ring
12		199014280042 [Sleeve]	Sleeve
13		190003559514 [Union nut]	Union nut
14		WG99100360253 [Ring]	Ring
15		WG99100360252 [Sleeve]	Sleeve
16		190003179778 [Plastic pipe]	Plastic pipe
17		190003179782 [Plastic pipe]	Plastic pipe
18		190003179781 [Plastic pipe]	Plastic pipe
19		190003179784 [Plastic pipe]	Plastic pipe
20		190003179785 [Plastic pipe]	Plastic pipe

BRACKET FOR BRAKE (C10-5) для Sinotruk 6x4 Tipper (290) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
1		AZ9719360013 [Bracket for 4-cir. protection valve]	Bracket for 4-cir. protection valve
2		199014360140 [Angle for relay valve]	Angle for relay valve
3		AZ961836001 [Angle for relay valve]	Angle for relay valve
6		AZ9130360003 [Angle for trailer control valve]	Angle for trailer control valve
7		AZ9719360014 [Bracket for air dryer]	Bracket for air dryer
8		1880 360083 [Carrier]	Carrier
9		199000360315 [Carrier]	Carrier
10		199012360441 [Angle]	Angle
11		199000362186 [Angle]	Angle
12		199100360165 [Angle]	Angle
13		1397 350169 [Angle]	Angle
14		199100360168 [Angle]	Angle
15		199100360241 [Angle]	Angle
16		199100360207 [Support]	Support
17		199100360228 [Lashing]	Lashing
18		199100360229 [Angle]	Angle
19		199114360101 [Angle]	Angle
20		AZ9718360007 [Connecting plate]	Connecting plate
21		AZ9100360120 [Angle]	Angle
22		26600360022 [Angle]	Angle
23		199100360166 [Angle]	Angle
24		AZ9719360031 [Combination bracket]	Combination bracket
25		AZ9719360028 [U-Bracket]	U-Bracket
26		AZ9719360029 [Bracket for coupling]	Bracket for coupling

RARTS FOR BRAKE (C10-6) для Sinotruk 6x4 Tipper (290) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
1		Q72312T5F [Gasket]	Gasket
2		190003098031 [Gasket]	Gasket
3		190003098015 [Gasket]	Gasket
4		WG9000360292 [Gasket]	Gasket
5		1406 070015 [Gasket]	Gasket
6		WG9100360319 [Gasket]	Gasket
7		1680 250092 [Gasket]	Gasket
8		138091360181 [Clamp]	Clamp
9		1188 730187 [Clamp]	Clamp
10		199000360408 [Clamp]	Clamp
11		1 93 760081 [Angle]	Angle
12		199100360174 [Clamp]	Clamp
13		1280 770028 [Clamp]	Clamp
14		199100360234 [Clamp]	Clamp
15		199100360134 [Distance sleeve]	Distance sleeve
16		199100360135 [Distance sleeve]	Distance sleeve
17		190003171390 [Wire fastener]	Wire fastener
18		190003171392 [Wire fastener]	Wire fastener
19		190003171393 [Wire fastener]	Wire fastener
20		190003559539 [Gasket]	Gasket
21		19900360477 [Gasket]	Gasket
22		1288730061 [O-ring]	O-ring
23		190003179045 [Protection sleeve]	Protection sleeve
24		1381F140090 [Protection sleeve]	Protection sleeve

AIR LINR FOR AXLE PNEU. DIFF. LOCK (C10-7) для Sinotruk 6x4 Tipper (290) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
1		190003179782 [Plastic pipe]	Plastic pipe
2		190003559766 [Nozzle]	Nozzle
3		199000360477 [Gasket]	Gasket
4		199014280016 [Sleeve]	Sleeve
5		190003559497 [Nozzle]	Nozzle
6		190003559561 [Cutting ring]	Cutting ring
7		190003559516 [Union nut]	Union nut
8		WG9100710008 [Magnetic valve]	Magnetic valve
9		1288 730061 [0-ring]	0-ring

6x4, 8x4 WHEEL PNEU. DIFF. LOCK FOR STEYR AXLE (C10-8) для Sinotruk 6x4 Tipper (290) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
1		190003179782 [Plastic pipe]	Plastic pipe
2		190003559766 [Nozzle]	Nozzle
3		190003559516 [Union nut]	Union nut
4		190003559508 [Union nut]	Union nut
5		190003559561 [Cutting ring]	Cutting ring
6		199014280016 [Sleeve]	Sleeve
7		190003559482 [Nozzle]	Nozzle
8		190003559497 [Nozzle]	Nozzle
9		199000360477 [Gasket]	Gasket
10		1288 730061 [O-ring]	O-ring

DOUBIE VOICE PNEUMATIC HORN (C10-10) для Sinotruk 6x4 Tipper (290) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
1		WG9716270003 [Double-voice horn]	Double-voice horn
2		AZ9716270005 [Bracket for horh]	Bracket for horh
3		Q150B0620 [Screw]	Screw
4		Q40306 [Washer]	Washer
5		Q340B06 [Nut]	Nut
6		190003179782 [Plastic pipe]	Plastic pipe
7		190003559766 [Nozzle]	Nozzle
8		199000360477 [Gasket]	Gasket
9		1288 730061 [O-ring]	O-ring
10		190003559482 [T-nozzle]	T-nozzle
11		199014280016 [Union nut]	Union nut
12		190003559561 [Cutting ring]	Cutting ring
13		190003559516 [Sleeve]	Sleeve
