Fig. 82: Installing Back Window Glass
Courtesy of FORD MOTOR CO.

4. If equipped, connect the rear window defrost connectors.

Vehicles with power sliding window

NOTE:

RH side shown, LH side similar.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 83: Installing LH And RH Rear Power Sliding Window Cable
Courtesy of FORD MOTOR CO.

5. Install the LH and RH rear power sliding window cable.

NOTE:

RH side shown, LH side similar.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 84: Installing LH And RH Power Sliding Window Cable Screws
Courtesy of FORD MOTOR CO.

6. Install the LH and RH power sliding window cable screws.

All vehicles

7. Position the headliner.

8. Install the pin-type retainers.

9. If equipped, install the dome lamp.

1. Position the dome lamp.

2. Install the dome lamp screws.

3. Install the lens.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 85: Installing Dome Lamp
Courtesy of FORD MOTOR CO.

10. Install the coat hooks.

1. Position the two coat hooks.

2. Install the two screws.
