Fig. 95: Disconnecting Exterior Door Handle Actuating Rod
Courtesy of FORD MOTOR CO.

11. Disconnect the door ajar switch electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 96: Disconnecting Door Ajar Switch Electrical Connector
Courtesy of FORD MOTOR CO.

12. Disengage the wiring harness locator.

13. Position the rear door latch aside.

z

Remove and discard the screws.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 97: Identifying Screws
Courtesy of FORD MOTOR CO.

14. Remove the rear door latch.

z

Disconnect the cable from the latch.

z

Transfer all necessary components.

15. To install, reverse the removal procedure.

z

If necessary, use Multi-Purpose Grease Spray F5AZ-19G209-AA or equivalent meeting Ford
specification ESR-M1C159-A to lubricate the latches.

TAILGATE LATCH

Removal

1. Open the tailgate.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 98: Opening Tailgate
Courtesy of FORD MOTOR CO.

2. Remove the tailgate access panel.

1. Remove the screws.

2. Remove the tailgate access panel.
