MOUNT - REAR REMOVAL 1. Raise the vehicle on a hoist. 2. Using a suitable jack, support transmission. 3. Remove the nuts from the transmission mount (1). 4. Remove the two bolts that attach the transmission mount to the engine bracket. 5. Raise the transmission enough to remove the mount from the crossmember (2). 6. Remove the mount (1). INSTALLATION NOTE: Threadlocking compound must be applied to the bolts before installation. 1. Install the two bolts that attach the transmission mount to the transmission bracket. 2. Torque the bolts to 61N·m (45 ft.lbs.) torque. 3. Lower the transmission so the transmission mount rests on the crossmember, and the studs of the transmission mount are aligned in the slots in the crossmember. 4. Install the nuts onto the transmission mount studs through the crossmember access slot. 5. Torque the nuts to 54N·m (40 ft. lbs.). LUBRICATION DESCRIPTION The lubrication system is a full flow filtration pressure feed type. 9 - 846 ENGINE - 3.7L SERVICE INFORMATION ND |
