P0335-CRANKSHAFT POSITION SENSOR CIRCUIT (CONTINUED) 4. (K900) SENSOR GROUND CIRCUIT OPEN Turn the ignition off. Disconnect the C2 PCM harness connector. CAUTION: Do not probe the PCM harness connectors. Probing Is the resistance below 5.0 ohms? Yes >> Go To 5 No >> Repair the open in the (K900) Sensor ground circuit. Perform the POWERTRAIN VERIFICATION TEST. (Refer 5. (K24) CKP SIGNAL CIRCUIT SHORTED TO THE (F855) 5-VOLT SUPPLY CIRCUIT Measure the resistance between the (K24) CKP Signal circuit and the Is the resistance below 5.0 ohms? Yes >> Repair the short between the (K24) CKP Signal circuit and the (F855) 5-volt Supply circuit. Perform the POWERTRAIN VERIFICATION TEST. (Refer No >> Go To 6 9 - 366 ENGINE ELECTRICAL DIAGNOSTICS ND |
