B1B71-UP-FRONT RIGHT SATELLITE ACCELERATION SENSOR INTERNAL (CONTINUED) 4. CHECK THE (R80, R82) FRONT RIGHT IMPACT SENSOR CIRCUITS FOR A SHORT TOGETHER Measure the resistance between the (R80) Front Right Impact Sensor Is the resistance below 100K ohms? Yes >> Repair the (R80, R82) Front Right Impact Sensor circuits shorted together. Perform the ORC VERIFICATION TEST - VER 1. No >> Go To 5 5. CHECK THE (R82) FRONT RIGHT IMPACT SENSOR GROUND CIRCUIT FOR AN OPEN OR HIGH Connect the 8443 Load Tool ORC Adaptor to the Occupant Control Measure the resistance of the (R82) Front Right Impact Sensor Is the resistance below 1 ohm? Yes >> Go To 6 No >> Repair the (R82) Front Right Impact Sensor 2 Ground cir- cuit for an open or high resistance. Perform the ORC VERIFICATION TEST - VER 1. 8O - 172 RESTRAINTS - ELECTRICAL DIAGNOSTICS ND |
