3. If equipped, install the shift boot (2), (Refer to 23 - BODY/INTERIOR/SHIFT BOOT-FLOOR - INSTALLATION). FULL FLOOR CONSOLE 1. Position the floor console (7) in the vehicle and connect the console assembly wire harness con- 2. Position the floor console to the floor panel and install the screws (2) (5) that secure the console to 3. Install the rubber liner (1). 4. Install the cup holder (3). 5. Install the tray (4). 23 - 212 INTERIOR ND |
