CAUTION: The door trim panel is attached to the 4. Position the door trim panel (3) and align the molded plastic retaining clips (6) to the door. 5. Lift the trim panel up and onto the lock rod (1) and attachment hooks (6). 6. Push the door trim panel straight downward until all of the retaining clips are fully engaged to the door. 7. Install the lower screws (5). 8. Install the screw (4) from the pull cup. 9. Install the screw (2) at the interior handle. 10. Install the manual window crank handle (2), if equipped. 11. Connect battery negative cable. REGULATOR-WINDOW - MANUAL REMOVAL 1. Remove the watershield. (Refer to 23 - BODY/ DOOR - FRONT/WATERSHIELD - REMOVAL) 23 - 72 DOOR - FRONT ND |
