In some cases, the end of the axle shaft will move and contact the mate shaft when the feeler gauge is inserted. 5. If there is no side gear clearance, remove the C-lock from the axle shaft. Use a micrometer to measure the thrust washer thickness. Record the thickness and re-install the thrust washer. Assemble the differential case 6. Compare both clearance measurements. If the difference is less than 0.012 inch (0.305 mm), add clearance recorded when the C-lock was installed to thrust washer thickness measured. The sum will determine the 7. If clearance is 0.012 inch (0.305 mm) or greater, both side gears must be replaced (matched set) and the clear- ance measurements repeated. 8. If clearance (above) continues to be 0.012 inch (0.305 mm) or greater, the case must be replaced. SPECIFICATIONS AXLE SPECIFICATIONS DESCRIPTION SPECIFICATION Axle Ratio 3.21, 3.55, 3.92 Differential Case Flange Runout 0.076 mm (0.003 in.) Differential Case Clearance 0.12 mm (0.005 in.) Ring Gear Diameter 209.5 mm (8.25 in.) Ring Gear Backlash 0.12-0.20 mm (0.005-0.008 in.) Ring Gear Runout 0.12 mm (0.005 in.) Pinion Bearing Preload - Original Bearings 1-2 N·m (10-20 in. lbs.) Pinion Bearing Preload - New Bearings 1.7-4 N·m (15-35 in. lbs.) TORQUE SPECIFICATIONS DESCRIPTION N·m Ft. Lbs. In. Lbs. Differential Cover Bolts 41 30 - Bearing Cap Bolts 95 70 - Ring Gear Bolts 102 75 - Pinion Nut Minimum 285 210 - Adjuster Lock Screw 10 - 90 Pinion Shaft Lock Screw 11 8 3 - 84 REAR AXLE - 8 1/4 ND |
