(8) Position zipper upper half listing at index marks on the third roof bow. Verify that start end of (9) Install staples to hold zipper listing to third roof bow (Fig. 8). (10) Position top cover hold down listing at index marks on third roof bow. (11) Install staples to hold top cover listing to third roof bow (Fig. 8). (12) Position stay straps at index marks on the third roof bow. (13) Install staples to hold stay straps to third roof bow. (14) Zip rear window into position. window up and over the third roof bow to the rear of (16) Position top cover at index marks at each end of rear tack strip. (17) Install staples to hold top cover to rear tack strip (Fig. 6). (18) Position side and rear tack strips behind quar- ter and deck panels. (19) Install bolts to hold side tack strips to inside of quarter panels (Fig. 6). (20) Install bolts to hold rear tack strip to deck panel. (21) Latch top header to windshield header and in- spect top cover for excess wrinkling. If wrinkling is (22) Route wire harnesses through pockets at each side of window and connect ends to terminals on (23) Install sling well and rear section of headlin- ing. FOLDING TOP COVER REMOVAL (1) Release folding top latches and allow top cover to relax. (2) Remove headlining. to rear deck and quarter panels. (4) Position sling well out of the way. deck panel. (6) Separate rear tack strip from deck panel. of quarter panels. (8) Separate tack strips from quarter panels. CAUTION: Cover all painted and upholstered sur- (9) Reposition tack strips above rear deck and quarter panels. (10) Using a grease pencil, mark location of outer top cover on rear tack strip to aid installation. (11) Remove staples holding top cover to rear tack strip. (12) Fold rear of top cover, tack strips and rear window up and over the third (rear) roof bow. (13) Unzip and separate rear window from vehicle. on third roof bow. (15) Remove staples holding top cover listing to third roof bow. (16) Remove screws holding roof rail tension cable springs to roof rear roof rail behind quarter glass (17) Pull quarter glass weatherstrips from roof rail channels. (18) Remove screws holding roof rail channels to roof rails. (19) Separate roof rail channels from vehicle. roof rail. (21) Lower folding top to the mid point. channel. Separate first 50 mm (2 in.) of weather strip (23) Remove screws holding weatherstrip channel to top header. (24) Separate channel from top header. strip to top header. (26) Separate feature strip from header. cable ends into key-hole slots in roof rails (31) Disengage roof rail tension cables from roof rails. (32) Pull tension cables from rear of pockets on back of top cover. (33) Remove screws holding top cover retainer rod to second roof bow. (34) Separate retainer rod from second roof bow. to first roof bow. (36) Separate retainer rod from first roof bow. of top cover. INSTALLATION The new top cover must be trimmed to the same size and shape as the old top cover to minimize wrin- 23 - 90 AJ/27-BODY Ä |
