EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES Inspection and adjustment 3-20 Adjusting the V-belt tension of the air Slacken the attachment bolt (1) in the 2. Slacken the attachment bolts on the 3. Reposition the compressor using the lock M2127 2 1 3 3 Adjusting the belt (10-rib) tension of fan and Slacken the attachment bolt (1) in the 2. Slacken the attachment bolt (3) in the 3. Shift the alternator using the lock nuts (4) M2128 1 2 4 4 3 Adjusting the belt (6-rib) tension of water Slacken the central nut (1) of the tensioner. 2. Shift the tensioner using the bolt (2) until the M2129 2 1 5 200424 |
