2 Removal and installation XE ENGINE 4-29 4.19 REMOVAL AND INSTALLATION, VIBRATION DAMPER Removing the vibration damper Remove the fixing nuts from the viscous fan 2. Remove the water pump, alternator and 3. Remove the fan pulley fixing bolts (9). 4. Remove the fan pulley (6). 5. Remove the fixing bolts (5) of the vibration 6. Remove the vibration damper (4). Installing the vibration damper Check the vibration damper for external 2. Fit the vibration damper (4). Tighten the 3. Install the fan pulley (6) on the fan drive and 4. Install the V-belts and check the V-belt 5. Install the viscous fan clutch and the fan. 9 6 5 3 2 1 8 M200945 5 ǹ 0008 |
