To perform the Quick Learn procedure, the fol- lowing conditions must be met. – It is imperative that the vehicle be shifted into OD with the engine running and the oil level – Place the selector lever in neutral. – The brakes must be applied. – The engine must be idling. – The throttle angle (TP sensor) must be less than 3 degrees. – The shift lever position must stay in neutral until prompted to shift into OD. – The shift lever must stay in OD after the 9Shift to Overdrive 9 prompt until the DRBIIIt indi- cates the procedure is complete. – The oil temperature must be between 15 C (60°) and 93 C (200° F). NOTE: The above conditions must be maintained during the procedure to keep the The Quick Learn procedure is performed with the DRBIII t by selecting 9Transmission9 system then 9Miscellaneous9 functions, then 9Quick Learn9. Fol- t. 3.3.7 CLUTCH VOLUMES Theory of Operation: The volumes of the trans- Transmission Effects: These CVIs that are out of Possible Causes: > Clutch pack clearance out of spec > Snap ring out of position or broken > Broken return spring > Hydraulic leak into clutch circuit with near-zero volume 3.3.8 EATX DTC EVENT DATA EATX DTC EVENT DATA can be used as a diagnostic aid when experiencing Electronic Trans- t. This infor- mation can be helpful when a DTC can not be The EATX DTC EVENT DATA is located in the DRBIII t, under the Transmission system menu, in the sub-screen Miscellaneous. It is a good practice A thorough understanding of how the transmis- sion works is beneficial in order to interpret the A MASTERTECH video and reference book was produced in January 2002 that explains many of EATX DTC EVENT DATA can only be erased by: 1. Disconnecting the battery. 2. Performing a DRBIII t QUICK LEARN proce- dure. 3. Reprogramming the NGC/EATX controller. Erasing Transmission DTCs does not clear the EATX DTC EVENT DATA. 3.3.9 ELECTRONIC PINION FACTOR (IF The transmission output speed signal supplies distance pulses to the control module, which are Using the following steps, the pinion factor can be checked and/or reset using the DRBIII t: 4 GENERAL INFORMATION |
