OIL PRESSURE
Description
Specification
Metric
Standard
(NOTE: At Normal Operating Temperatures)
Pressure @
Curb Idle
Speed*
34.7 kPa Min.
5 psi Min.
Description
Specification
Metric
Standard
Pressure @
3000 RPM
300–724 kPa
45–105 psi
*CAUTION: If oil pressure is zero at idle, DO NOT run
engine at 3000 RPM.
TORQUE
DESCRIPTION
N·m
Ft.
Lbs.
In.
Lbs.
A/C Compressor to Engine - Bolts
28
21
-
Camshaft Sprocket - Bolts
28
-
250
Camshaft Chain Tensioner (Secondary) - Bolts
12
-
105
Camshaft Bearing Cap - Bolts
12
-
105
Connecting Rod Cap - Bolts
27 +
1
⁄
4
Turn
20 +
1
⁄
4
Turn
-
Crankshaft Main Bearing Cap - Tie Bolts
28
-
250
Crankshaft Main Bearing Cap - Outer Cap Bolts
27 +
1
⁄
4
Turn
20 +
1
⁄
4
Turn
-
Crankshaft Main Bearing Cap - Inner Cap Bolts
20 +
1
⁄
4
Turn
15 +
1
⁄
4
Turn
-
Crankshaft Damper - Bolt
170
125
-
Cylinder Head - Bolts
(Refer to 9 - ENGINE/CYLINDER HEAD -
INSTALLATION)
Cylinder Head Cover - Bolts
12
-
105
Exhaust Manifold - Bolts
23
-
200
Exhaust Manifold Heat Shield - Bolts
12
-
105
Exhaust Manifold to Catalytic Converter V-Band Clamp
11
-
100
Engine Mount Bracket to Block - Bolts
61
45
-
Engine Mount Isolator - Nuts
61
45
-
Intake Manifold (Upper and Lower) - Bolts
12
-
105
Generator Bracket-Bolts
41
30
-
Oil Pan - Bolts
28
-
250
Oil Pan - Nuts
12
-
105
Oil Pan Drain - Plug
27
20
-
Oil Filter
16
12
-
Oil Pump to Block - Bolts
28
-
250
Oil Pump Cover - Bolts
12
-
105
Oil Pump Pick Up Tube - Bolt
28
-
250
PCV Valve
7
-
60
Crankshaft Rear Seal Retainer - Bolts
12
-
105
Spark Plugs
20
15
-
JR
ENGINE 2.7L DOHC
9 - 167
